Wedge Wire/Mesh

Specifications

Wedge wire tube is composed of rib strips and V shaped wires through manufacturing on specialized welding.

Description of Wedge Wire Mesh

 Wedge-Shaped Wire is composed of rib strips and V shaped wires through manufacturing on specialized welding machine. The rib strips and V shaped wires will be welded by resistance welding, has enough welding strength, equally slot gap, high corrosion resistance, large filter area, good permeability, simple structure, 0.1mm slot gap, and can be select  by client in any way.



Features and Advantage

1. It has high mechanical strength, can bear large pressure drop.

2. It has equal slots for filtering, can form equally distributed filter cake, easy to clean for reuse.

3. The wedge type slot can improve backflushing and regeneration performance.

4. It has resistance to pressure, temperature, aging, corrosion, can be applied for different kinds of fluid.



Wedge wire specification



Outside diameter (mm)	Sewing (mm)	Standard length (mm)	Filter Wire (mm)	Support Wire
4'' ,6'' ,8'' 10'',12'' and etc.	0.1-35	50-6000	2.2*3.0mm	3.8mm/22pieces
			2.3*3.0mm	3.8mm/32pieces
			3.0*4.6mm	3.8mm/48pieces
			3.0*5.0mm	3.8mm/50pieces
