Model

30 hp

Type

4×2 Wheeled Tractor

Rated Tractive Force (kN)

6.5

Overall Dimensions(L*W*H, mm)

2500*1250*1380

Structural Mass (kg)

1070

Min. Operating Mass (kg)

1160

Wheelbase (mm)

1560

Wheel Tread (Front/Rear, mm)

980~1200/1010~1200(can be adjusted)

Min. Ground Clearance (mm)

370

Min. Turning Radius (m)

4.2

Calculating Speed (km/h)

forward

2.21/3.37/4.61/6.38/8.88/13.59/21.33/29.41

reverse

2.54/12.27

Hitch Linkage

I Type, Rear-Mounted, Three-Point Linkage

PTO Shaft Type

Rear-Mounted, Dependent, 540 rpm, Clockwise, Φ 35mm

Tire Detail(Front/Rear)

5.00-16/9.5-24

Engine

Model

JD2102

Type

Double Cylinder, Vertical, Water-cooled, 4-stroke

12-hour Rated Power (kW)

22.1

Rotate Speed (r/min)

2400

Starting Method

Electric

Bore×Stroke (mm)

100×105

Fuel Oil Consumption (g/kw*h)

≤250

Lubricating Oil Consumption (g/kw*h)

≤2.04
