China Agricultural Machinery Cheap 4WD 80hp Farm Tractor For Sale

No.

Item

Qty

Unit Price

(EXW-USD)

Amount

(EXW-USD)

1.

TB55hp4wd

1SET

7559

7559

2.

TB60hp4wd

1SET

7716

7716

QuanChai/new diesel engine, 8.3-20/12.4-28 tires, 12 + 12 shuttle shift, 10 inch double-acting clutch, double speed and four-wheel drive, hydraulic steering and suspension components

3.

TB80hp4wd

1SET

8818

8818

QuanChai/new diesel engine, 8.3-24/14.9-30 tires, 12 + 12 shuttle shift, 11 "double-acting clutch, double speed and four-wheel drive, hydraulic steering, and brake, strong up strong, with suspension components

Total FOB QINGDAO,CHINA PRICE (Validity time:30days )

Shipping to Hobart  freight cost

Total CIF QINGDAO Port (Validity: 30 days)

a. -40HQ ctn can load

b.-Delivery time:30days after an order

c.-Payment terms:30% down payment,70% to be paid before delivery

HW 554 SPECIFICATION

Model

HW554

Drive type

4*4

Engine

Engine brand

QC

Model

QC4105T55

Type

water-cooling,  In-line, 4 stroke

Capacity of fuel tank(L)

41

Bore*Stroke

105*118

Rated speed (r/min)

2400

Engine power (hp)

55hp

Displacement

4.087L

Transmission

Clutch

Dry, Single type

PTO size

6teeth-φ35,8teeth-φ38

PTO Speed(rpm)

540/760   760/1000

Gear shift

12F+12R

Hydraulic system

Hydraulic output valve

2-Way optional

Three point linkage

Category of 3-point link

Category I

Lifting capacity(at point
of 610mm)KN

>6.6

Technical parameter

Dimension(L*W*H) mm

4050*1650*2060

Min.operation weight

2356kg

Wheel base(mm)

1980

Track base(mm) front wheel

1290

Track base(mm) rear wheel

1300

The smallest clearance(mm)

300

Front tyre

8.3-20

Rear tyre

12.4-28

Steering type

Hydraulic power steering

Model

HW804

Drive type

4*4

Engine

Engine brand

QC

Model

4108

Type

4 cylinder, water-cooling, In-line, 4 stroke

Bore*Stroke

105*135

Rated speed (r/min)

2200

Engine power (hp)

90hp

Displacement

4.68L

Transmission

Clutch

Dry, Dual-stage type

PTO size

8 teeth, φ38

PTO Speed(rpm)

540/760

Gear shift

10+10 shuttle shift

Hydraulic system

Hydraulic output valve

2-Way

Three point linkage

Category of 3-point link

Rear, Category II

Technical parameter

Dimension(L*W*H) mm

4285*1910*2760

Min.operation weight

3580kg

Wheel base(mm)

2200

Track base(mm) front wheel

1450

Track base(mm) rear wheel

1430-1830 (usual 1530)

Min. clearance(mm)

335

Front tyre

8.3-24

Rear tyre

14.9-30

Steering type

Hydraulic steering

Model

FOB Price(USD)

Front ballast

+126

Rear ballast

+63

Air brake

+79

Sun shade

+189

One set of hydraulic output

+157

Two sets of hydraulic output

+251

Cabin

+787

Shuttle shift
