Help Center50mm Synchronous Motor
US$ 1.2 - 3
MOQ: 5000 Pieces
Key Specifications
Get Latest Price
Brand Name:
Huayang
Model Number:
50TYZ
Type:
Synchronous Motor
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
Huayang
Model Number
50TYZ
Type
Synchronous Motor
Frequency
50/60
Output Power
3~7w
AC Voltage
208-230 / 240 V
Specifications
Our synchronous motors are widely used in air conditioners, dishwashers, refrigerators and other home appliances.Model No. |
Diameter mm | Height mm | Rated Voltage V.AC) | Rated Frequency (HZ) | Rated Power W) | Rated current mA) | Start Voltage under load (V) | Output Rotation speed r/min) | Output TorqueKgf/cm) | Insulation Resistance MΩ) | Insulation dielectric intensityV/S) | Noise dBA) | Temperature rise(K/264V) | Insulation Class |
| SM008 | 50 | 17 | 220/240 | 50/60 | 3 | 25 | 176 | 2.5~3 | ≥5 | ≥100 | 1800 | < 40 | < 75 | E |
| SM021 | 50 | 20.5 | 220/240 | 50/60 | 2.5 | 20 | 176 | 5~6 | ≥5 | ≥176.4 | 1800 | < 40 | < 75 | E |
| SM015C | 50 | 17 | 220/240 | 50/60 | 4 | 25 | 4.1/5 | ≥4 | >100 | 1800 | < 45 | < 60 | E | |
| SM015D | 50 | 20.5 | 220/240 | 50/60 | 4 | 25 | 4.1/5 | >500 | >100 | 1800 | < 45 | < 60 | E | |
| 50KTYZ637-DQ5 | 50 | 37.5 | 220/240 | 50/60 | 10 | 35 | 176 | 8/10 | ≥850 | ≥100 | 1800 | 40 | 65 | E |
| 50TYZ622-FQ1 | 50 | 23 | 220 | 50 | 4 | 35 | 176 | 3 | ≥10 | >50 | 1800 | < 35 | < 50 | E |
| SM50B | 50 | 37 | 220/240 | 50/60 | 7 | 35 | 176 | 11.5/13.8 | ≥800 | ≥100 | 1800 | 40 | 75 | E |
| SM060A | 60 | 57.8 | 220/240 | 50 | 14 | 40 | 154 | 20/24 | ≥1000 | >100 | 1800 | < 40 | < 75 | E |
| 60KTYZ-07 | 60 | 60 | 110 | 50 | 19 | 25 | ≥100 | 40 | < 75 | E | ||||
| TYZ50-AE7 | 50 | 24.5 | 220/240 | 50/60 | 4.5 | 187 | 4.1/5 | ≥700 | ≥100 | 1800 | 40 | 60 | E | |
| TYZ50-AE5 | 50 | 20.5 | 220/240 | 50/60 | 4 | 25 | 165 | 4.1/5 | ≥430 | ≥100 | 1800 | 40 | 60 | E |
| SM002 | 50 | 20.5 | 220/240 | 50/60 | 4 | 4.1/5 | ≥400 | ≥100 | 1800 | 40 | 60 | E | ||
| SM016 | 50 | 20.5 | 220/240 | 50/60 | 4 | 20 | 168 | 4.1/5 | ≥430 | >100 | 1800 | < 40 | < 75 | E |
1. Company Profile
nFounded in 1995.
nCovers around 800,000 floor areas totally in two manufacturing locations with advanced facilities and equipment.
n Fixed assets around US$ 50 Million.
n Employs around 800 professional qualified staff and are united by Huayang unique cultures and purpose, which over 30% are university and college graduates.
nCertificated by ISO9001, ISO14001, ISO 13485, CCC, SGS,UL, VDE,CE TUV, CE, SFDA, etc.
nExcellent quality control to ensure there never bill be any deviation in the high standards of our products.
nEndeavors to deliver the highest quality products with tested long life, reliable performance and smooth operation in its applications duties and value-added
2. Products Performance
