Home > Products > Pipe Threading Lathe > QK1313 CNC Pipe Threading Lathe Machine Oil Pipe Threading Lathe With CE ISO
QK1313 CNC Pipe Threading Lathe Machine Oil Pipe Threading Lathe With CE ISO
- 50 Set / Sets per Month
- Qingdao
- T/T Credit Card
You May Like
-
QK1343 CNC Pipe Threading Lathe/ Oil Country Pipe CNC Lathe Machine
-
QK1335 CNC Pipe Threading Lathe/ Oil Country Pipe CNC Lathe Machine
-
QK1327 CNC Pipe Threading Lathe/ Oil Country Pipe CNC Lathe Machine
-
QK1322 CNC Pipe Threading Lathe/ Oil Country Pipe CNC Lathe Machine
-
QK1319 CNC Pipe Threading Lathe Machine Oil Country Pipe Turning Lathe
-
QK1313 CNC Pipe Threading Lathe/ Oil Country Pipe CNC Lathe Machine
Product Details
| Condition | New | Type | Horizontal | |
| CNC or Not | CNC | Automatic Grade | Automatic | |
| Max. Swing Diameter | 630mm | Place of Origin | Shandong, China | |
| Brand Name | HANKUI | Model Number | QK1313 | |
| Voltage | 220V/380V | Power(W) | 11kw | |
| Dimension(L*W*H) | OPTIONAL | Weight | As requirements | |
| Certification | ISO9000 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Pipe threading lathe series are mainly used for processing all kinds of pipe threads including inner, outer, taper, metric and inch thread etc., and also undertake various turning works such as inner and outer cylindrical surface, conical surface and end surfaces.
Standard: Spindle 820rpm, 11kw Frequency conversion(630x1500mm)
CNC control system: Siemens
Electric vertical four position turret
The diameter of 400mm three jaw manual chuck
Optional system: GSK, KND, FANUC
Optional: The diameter of 500mm chuck
Optional : Working length 2000, 3000mm
Optional : Center rest, follow-rest
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
