Specifications
4-CH diversity simultaneous receiving functionHigh capacity of inset DVR records
COFDM module
DVD video
AES/ABS Encryptio
4-channel wireless video receiver
MV2025RH7/4-JKYZ 4-CH Portable Receiver
System Introduction:
The 4-CH Portable Receiver is specially designed for multi-channel receiving application. It can receive audio and video from four transmitters (MV2025 series transmitter) at the same time. The whole system adopts the latest technologies of COFDM modulation and MPEG-2 image compression that enables good NLOS (Non line-of -sight) transmission with DVD quality video. And the built-in 4-picture DVR (Maximal capacity is 500GB) can record the real-time audio and video. Users can play back the recorded image any time on the computer. Users can choose the portable mini transmitter (MV2025TTLE) to finish covert mission. The encryption of AES128 bit/ ALLTECH Basic Scrambling ensure the transmission security. The whole system is highly integrated and can realize wireless video transmission in mobile and NLOS (Non line-of-sight) conditions.
System Features:
4-CH diversity simultaneous receiving function
High capacity of inset DVR records the real-time audio and video
COFDM modulation, stable transmission.
Real-time audio and video with DVD quality
Transmission security by encryption of AES128 bit/ ALLTECH Basic Scrambling
MPEG-2 video compression
High capacity of Lithium battery for power supply
Modular design and highly integrated
Adjustable working frequency
High strength aluminum enclosure, dustproof, waterproof and shockproof
NLOS (Non line-of-sight) transmission.
The transmission range is more than 30Km in LOS (line-of-sight) condition
Good transmission with high definition video and stereo audio
System Application:
The 4-CH receiver is portable. Inset lithium battery for the power supply of the system. The continuous working time can be 1.5hours. Because of the strong enclosure, it is waterproof and shakeproof. Users can put it anywhere outside.
Transmitter Specification
Frequency |
300-400MHz, 400~800MHzcustomized, |
Power output |
500mW |
Bandwidth |
8 MHz7MHz6MHz2.5 MHz1.25MHz(optional) |
Modulation |
COFDM |
Constellation |
QPSK,16QAM,64QAM (optional) |
Carrier |
2K |
FEC |
1/2,2/3,3/4,5/6, 7/8(optional) |
Guard interval |
1/32,1/16,1/8,1/4(optional) |
Video compression |
MPEG2 420 |
Latency |
< 100ms |
Motion speed |
>280km/h |
Li-battery |
DC10.8V /1800mAh |
Battery charger |
12.6V/2A |
RF interface |
SMA |
Ambient humidity |
≥95% |
Temperature |
-40°C~+45°C |
Weight |
Transmitter0.27Kg Battery0.22 Kg |
Dimension |
Transmitter109.5mm*85mm*17mm Battery113mm* 85mm*13.2mm Transmitter and Battery combined: 113mm*85mm*30mm |
4-Ch Receiver Specification:
Working voltage |
AC220V±20V, DC14V~DC16V |
|
Working current |
≤6A@ DC15.5V |
|
Working frequency |
170MHz~860MHz |
|
RF bandwidth |
1.25/2.5MHz or 6/7/8MHz |
|
Receiving sensitivity |
≤-103dBm @ 1.25/2.5MHz, ≤-94dBm @ 6/7/8MHz |
|
Modulation |
OFDM |
|
Constellation |
QPSK/16QAM @ 1.25/2.5MHz, QPSK/l6QAM/64QAM @ 6/7/8MHz |
|
FEC |
1/3,2/3 @ 1.25/2.5MHz, 1/2, 2/3, 3/4, 5/6, 7/8 @ 6/7/8MHz |
|
Carrier |
2K |
|
Guard interval |
1/8, 1/16 @ 1.25/2.5MHz, 1/4, 1/8, 1/16, 1/32 @ 6/7/8MHz |
|
Video output |
1~1.2Vp-p@75Ω |
|
Video mode |
PAL/NTSC |
|
Magnitude-frequency(dB) |
0~4.8MHz |
-0.5~1.5 |
5.5MHz |
-4.0~1.5 |
|
Rx feeding voltage |
DC10V~DC12V |
|
Rx feeding currentMAX |
800mA/line |
|
Audio output |
Right/left, stereo |
|
RS232 control interface |
Standard RS232 level,9600,8,N,1 |
|
RS232 data interface |
Standard RS232 level,support 1200~115200 |
|
Video feature |
Support 4-ch A/V input |
|
Recording video quality |
CIF/HD12 (optional) |
|
Video output |
Support composite video output and playback |
|
Picture display |
4-picturescreen and 1-pictre screen (optional) |
|
Motion detection |
available |
|
Size (mm) |
L600 * W391 * H230 |
|
weightincludes Li battery |
16.8(Kg) |
|
Lithium battery capacity |
14.8V/8AH |
|
