2x2 LED Volumetric Troffer
- UL, cUL and DLC listed
- Osram/Espen LED driver with local warranty backup
- 2x2 size
- Linear ribbed acrylic diffusers
- Ideal for installation in T-bar grid or drop-in ceilings
- 120-277VAC input (347V optional)
- 3000K, 3500K, 4000K, 5000K CCT
- Typical 100 LPW
- 0-10V dimming comes standard
- Battery pack available
- 5 years warranty
The VTSL22 LED volumetric troffer comes with one LED engines and is a cost-effective replacement for traditional fluorescent troffers. The fixture accepts 120-277VAC, consumes 24W (36W optional) and produces light intensity equivalent to 3xF16T8 fluorescent fixture.
The VTSL22 offer a high performance optic system, advanced light distribution and architectural styling that deliver unprecedented value and quality. The fixture is ideal for installation in T-bar grid or drop-in ceilings and delivers excellent color rendering and smooth light output from ceiling to floor in offices, schools, hospitals, government buildings, retailers and other commercial settings.
Performance Summary
Input voltage: 120-277VAC, 50/60Hz |
|
Input wattage: 24 watts (2xF16T8 fluorescent fixture equivalent) 36 watts (3xF16T8 fluorescent fixture equivalent) |
Efficacy: 90-100 LPW |
|
Lumen output: 2300 lumens 3500 lumens |
CCT: 4000K Standard |
CRI: 80 min. |
L70 life: 50,000 hours |
Warranty: 5 years |
|
PHYSICAL SPECIFICATION | |
Length |
23.80” (605mm) |
Width |
23.80” (605mm) |
Height |
3.62” (92mm) |
Housing material |
Cold-rolled steel |
Finish |
White |
MOUNTING AND WIRING | |
Mounting |
Drop-in or suspended |
ENVIRONMENTAL SPECIFICATION | |
Operating temp. |
-30–130°F (-34–54°C) |
Storage temp. |
-40–140°F (-40–60°C) |
Ingress protection |
Suitable for indoor and damp locations |
ELECTRICAL SPECIFICATION | |
Input voltage |
120-277VAC, 50/60 Hz |
Input wattage |
24W 36W |
Equivalent wattage |
3xF16T8 fluorescent |
Power factor |
0.90 min. |
Total harmonic distortion |
20% max. |
OPTICAL SPECIFICATION | |
Luminous flux |
2300 lm 3500 lm |
Efficacy |
90-100 lm/W |
CCT |
4000K
|
CRI |
80 min. |
Lens |
Diffused |
LIGHTING CONTROL | |
Dimming capacity |
0-10V dimming, 10-100% |
LONGEVITY AND WARRANTY | |
L70 life |
50,000 hrs. |
Warranty |
5 years |
LISTING AND CERTIFICATES | |
UL, cUL DLC | |
CE, RoHS | |
1. Are you factory direct?
Yes, we have our own factory, all of our products are with competitive factory price.
2. Do you have a special price and service for wholesale?
Yes, we have the most competitive and best service to support our wholesale customers. We do supply OEM&ODM service for the wholesale, also private label is available.
3. What payment methods can I use?
You can pay by T/T, Paypal, LC.
4. How long does it take for my order to be shipped?
Generally, your order will be shipped within 7-15 working days after your payment verified. But in cas e of any hot products without raw material, it will need 15-25 days.
5. How about the warranty?
We offer 5 years warranty. All products are gone through strict test by our experienced QC before shipment.
6. How about the after sale service?
Once there is any bad defect during your usage or the new goods go bad,we will solve it for you or send you a new one for free.
