Help CenterCOL370i DVB-C SD Set Top Box MPEG-2 With Low Bit-rate
Related Products
-
COL502T DVB-T SD Set Top Box, Mpeg-2 Dvb-t Digital Set Top Box With COFDM Modulate ModeNegotiableMOQ: 1 Piece -
COL1080C Dvb-c hd Set Top Box, Set Top Box With Hdmi Output, Dvb-c Set Top Box Mpeg2 Mpeg4NegotiableMOQ: 1 Piece
-
COL601M Isdb-t Mpeg-2/mpeg-4/h264,sd/hd Set Top Box With HdmiNegotiableMOQ: 1 Piece
-
COL7828S DVB-S/-S2 HDTV/SDTV MPEG-2/MPEG-4/H.264 Digital TV Set Top Box With HDMI InterfaceNegotiableMOQ: 1 Piece
-
Popular Catv Equipment DVB-C Decoder Set Top Box TV BoxUS$ 1 - 50MOQ: 1000 Pieces
Specifications
1. PAL/NTSC auto switching, EPG pre-viewing2.supports text messaging and program editing, mobile and deleting
3.LED display
Outline
The device meets the DVB –C standard and supports English and Chinese interfacing as well as multi condition receiving system, PAL/NTSC auto switching, EPG pre-viewing. It supports text messaging and program editing, mobile and deleting etc. It contains the Locking functions, Power-off memory, LED display, one key return and supports single voice channel, dual voice channel and stereo channels. It contains a range of games and supports Loader technology, on-line upgrade, on display of advertises and advertise menu.
Specifications
Input Features | |||||||
Input frequency range |
110 ~ 862MHz |
Symbol rate range |
3.6~6.952MS/S |
||||
Input impedance |
75Ω |
Input level |
35 ~ 85 dBuV |
||||
Video Features | |||||||
Decode format |
MPEG-Ⅱ |
Bit rate |
2 ~ 15Mbps |
||||
Output format |
NTSC/PAL |
Video output |
1V±20mV(p-p) |
||||
Image resolution |
720*480 /720*576 |
Frequency feature |
±0.8dB(≤4.8MHz) |
||||
Differential Gain |
≤8% |
Differential phase |
≤8° |
||||
Light delay |
≤50ns |
Noise figure |
6dB(typical) 9dB(max) |
||||
Audio Features | |||||||
Audio output |
L/R |
Audio S/N |
≥70dB |
||||
Output type |
RCA |
Audio distortion |
≤1.5% |
||||
Left right channel level difference |
≤0.5dB(60Hz~18KHz) |
||||||
Signal demodulator | |||||||
Demodulate mode |
QAM 16/32/64/128/256 |
LNB voltage |
0V / 18V |
||||
Power supply |
AC100V ~ 240V |
Power Consumption |
< 15W |
||||
