10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line

10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line thumbnail-1
10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Chemical, Other, Food, Chemical, Machinery & Hardware
Packaging Type:
Cans, Barrel
Contact Supplier Request Quote Chat Now
Suzhou First Packing Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Food, Chemical, Other, Food, Chemical, Machinery & Hardware
Packaging Type Cans, Barrel
Packaging Material Metal, Other, Metal, plywood case
Automatic Grade Semi-Automatic
Driven Type Electric
Voltage 380v
Place of Origin Jiangsu, China
Brand Name SUZHOU FIRST
After-sales Service Provided Engineers available to service machinery overseas

Specifications

10-20l Enclosed Round Cans production line
1,semi-autoatic
2,delievery in tme
3,good prce

Production details:





Slitting Machine  GTIB-15

10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line



Thickness

0.18-0.5 mm

Sheet Width

60-1050 mm

Capacity

1.6 m/min

Power

1.1kw

Net Weight

1100 kg

Dimension

1500×1200×1100mm





Automatic Round Shape Roller Machine  CY400-A



10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line



Diameter Range

100- 300mm

Thickness

0.20-0.35mm

Max .Width

400mm

Capacity

≤30cpm

Net Weight

650kg

Dimension

 1300*730*1330mm



 Welding Machine  FB2000-A

10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line







Power

3N.380V/50Hz15KVA

Welding speed

 ≤12m/min

Capacity

20~50cans/min

Welding Frequency

100~250Hz

Diameter Range

 φ65~φ300mm

Height Range

70~400mm

Overlap

 0.6~1.2mm

Materials

 Tin plating steel sheet

 T2~T3

Thickness

0.2~0.38mm

Copper Wire Diameter

1.5-1.7mmT2

Cooling Water

 ≥0.4MPa10L/min

Dimension

1350×1300×1700mm



Hydraulic Expanding Coning Machine  3TA20

10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line



Thickness

≤0.5mm

Diameter Range

 210-300

Height Range

 270-400

Capacity

15cans/min

Power of motor

5.5kw

Net Weight

 900kg

Dimension

 1300x780x1150mm







Hydraulic  Beading Machine 3TC20

 10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line

Thickness

≤0.5mm

Diameter Range

 210-300mm

Height Range

270-400mm

Capacity

15cans/min

Power of motor

5.5kw

Net Weight

950kg

Dimension

1470x940x1980mm



Seaming Machine(4 wheels)GT4A39-R



 10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line

Capacity

≤ 20cans/min

Diameter Range

210-300mm

Cooling Water

 ≥0.5MPa

Irregular Can(Diameter)

50-330mm

Height Range

60--400

Thickness

≤ 0.4mm

Net Weight

800kg

Power of motor

2.2kw

Dimension

1000x600x2000mm



Single-Ram pneumatic spot welder DN40-A



 10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line

Power

 3N38050HZ   40KVA

Thickness

0.2—0.5

Capacity

20-30cans/min

Compressed air

300L/min 0.6Mpa

Electrode journey

50mm

Net Weight

 300kg

Dimension

 80*60*140mm





Sample cans we can make:



10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line



 Customers from all over the world:



10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line



Company picture:



10-20l Encolsed Round Tin Can Production Line /Semi-automatic Can Making Line
