8ch dvbt 2 demodulator with ip output

Input Frequency Range:

47-862MHz

Symbol rate:

0.45-7.0MBauds

Input Level:

-15-20dBmV

Demodulation Mode:

16/32/64/128/256 QAM

Input Frequency Range:

950-2150MHz

Symbol rate:

 2-45Msps

Signal Strength:

-65- -25dBm

FEC Demodulation:

 1/2, 2/3, 3/4, 5/6, 7/8 QPSK

Input Frequency Range:

146-862MHz

Bandwidth:

8MHz (2, 6, 7MHz Optional)

Input Level:

-87- -20dBm

Constellations:

QPSK,16QAM,64QAM

FEC Demodulation:

1/2, 2/3, 3/4, 5/6, 7/8

Input Frequency Range:

950-2150MHz

Input Level:

-65- -25dBm

Code Rate:

1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10

Symbol ratio:

1-45Msymbols

Input Impedance:

75Ω

Demodulation Mode:

QPSK, 8PSK

Frequency Stepping:

500 KHz

Input Frequency Range:

170~230Mhz and 470~860Mhz

Bandwidth:

6MHz ( 6, 8MHz Optional)

Input Level:

0~-95dBm

Constellations:

QPSK,16QAM,64QAM

Code rate

1/2, 2/3, 3/4, 5/6, 7/8

DVB-CI module

Descrambling procession

Supporting European DVB-CSA

Smart Card interface

ISO7816

Interface Card separation

PCMCIA

ASI input

BNC connector 1 route input; 2 routes output

Input impedance 75Ω

Maximum transmitting rate

54Mbps

ASI   output

BNC connector 1 route input; 2 routes output

Output impedance 75Ω

Maximum transmitting rate

54Mbps

Ethernet

Connector

RJ-45

Interface Type

10/100 Base-T

Protocols

TS Over IP : UDP, NMS : UDP

Video output

CVBS×1 (BNC)

576 i25 fps, 480i 29.94 fps

YPbPr×1 (BNC)

1080i 25 ,29.94fps

720p  50 59.94fps

SDI×1 (BNC)

1080i25 ,29.94fps;720p  50 59.94fps 576i25 fps480i29.94 fps

HDMI×1

1080i25 ,29.94fps720p 50 59.94fps 576i25 fps;480i29.94 fps

Audio output

Stereo unbalanced audio

 BNC interface

Stereo balanced audio

 XLR interface

Digital audio

 SPDIF

General

Dimensions ( L×W×H)

482mm×360mm×45mm

Approx weight

3.2kg

Power

<20W(Max)

Temperature range

0~45°C (Operation); -20°C~80°C (Storage)
