Encoder,tv Encoder,ip Encoder,HDMI Encoder, Mpeg-2/h.264 HD Flash Encoder COL5100F

Name: Encoder,tv Encoder,ip Encoder,HDMI Encoder, Mpeg-2/h.264 HD Flash Encoder COL5100F
Brand: COLABLE
SKU: 121883495

US$ 1 - 2,999 MOQ: 1 Unit

Key Specifications

Place of Origin:

Sichuan, China

Brand Name:

COLABLE

Model Number:

COL5100F

Colable Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Chengdu

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Sichuan, China

Brand Name COLABLE

Model Number COL5100F

Specifications

H264 video compression and AAC/G.711/PCM audio compression
Check/upgrade/maintain device through network
Real-time TS stream

Features

l H264 video compression and AAC/G.711/PCM audio compression technology, high compression rate, able to proceed capsulation by TS stream

l Support TCP/IP protocol suite, AV over TCP/IP to transmit

l Support PTZ for setting and calling preset position, cruise and track

l Support dry contact, like alarm input/output, audio alarm

l Support PAL/NTSC

l Support POE

l Support OSD

l Support OVERLAY

l Support MOTION-DETECT

l Support TCP/UDP/ RTMP

l Able to check device state through network

l Able to upgrade through network as well as maintenance

Input		1×CVBS inputs, BNC interface
		1xS-VIDEO
		1xVGA, DB15 interface
		1xYPbPr input, BNC interface
		1xHDMI input, Compatible with hdmi1.2 as well as up
		1x3GSDI input, BNC interface
		Microphone, RCA, unbalanced stereo audio inputs, BNC interface
		XLR,AES, balanced audio inputs
Video		Resolution	1920x1080_30p 1920x1080_60i,1920x1080_50i 1280x720_60p,1280x720_50p 720x576_50i, 720x480_60i 1024x768(xga), 640x480(vga) 704x576(4cif), 704x480(4sif) 352x288(cif), 352x240(sif)
		Encoding	MPEG-4 AVC/H.264 Main Profile Level 4.1
		Bit rate	0.128Mbps~8Mbps
		Rate Control	CBR/VBR
		GOP Structure	IP, IBP, IBBBP, IBBBBBBBP, IP-LOW-DELAY
		GOP Mode	Simple/Advanced
		Advanced Pretreatment	De-interlacing, noise reduction, sharpening
Audio		Encoding	AAC, G711, MPEG-2 Layer 2 (optional)
		Sampling rate	48KHz, 44.1KHz
		Resolution	16 bit
		Bitrate	64Kb/s (each channel)
Monitor			1xYPbPr Direct output
Stream output			1 × ASI output, BNC interface
			COL5100F over RTMP,10/100Base-T Ethernet interface
			ES over UDP, TCP, UDP_MULTICAST
System function			DSMonitor operating and management WEB based operating and management
			Ethernet software upgrade
General	Dimensions (WxDxH)		44mm×181mm×258mm 44mm×278mm×258mm
	Approx weight		≤1Kg
	Temperature range		0~45°C(Operation), -20~80°C(Storage)
	Power requirements		DC12V
	Power consumption		15W
