SD H.264 Encoder 4 in 1, Sdi to ip Encoder Converter

Name: SD H.264 Encoder 4 in 1, Sdi to ip Encoder Converter
Brand: colable
SKU: 121882843

Negotiable MOQ: 2 Packs (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Sichuan, China

Brand Name:

colable

Model Number:

COL5141C

Colable Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

hongkong/shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Sichuan, China

Brand Name colable

Model Number COL5141C

Specifications

SD H.264 Encoder 4 in 1;
1.4 channels SDI input;
2.1 ASI input multiplexing;
3.eal-time effective output bit-rate monitoring

SD H.264 Encoder,SDI mpeg4 encoder,

Features

H.264/AVC High Profile Level 3.0 video encoding support, advanced video pretreatment algorithm
Supports MPEG1 Audio Layer 2
4 SD-SDI input interfaces
1 ASI input multiplexing support
Multiplexed MPTS ASI output support
Multiplexed MPTS over UDP unicast/multicast output
LCD / keyboard operating
Real-time effective output bit-rate monitoring
NMS support

Specifications

Input		4× SD-SDI inputs , BNC interface
Input		1×ASI input, BNC interface
Video		Resolution	720×480_60i, 720×576_50i
		Encoding	MPEG-4 AVC/H.264 High Profile Level 3.0
		Bit rate	0.8Mbps~20Mbps each channel
		Rate Control	CBR/VBR
		GOP Structure	IBBP
		Advanced Pretreatment	De-interlacing, noise reduction, sharpening
Audio		Encoding	MPEG-1 Layer 2 AAC(optional)
		Sampling rate	48KHz, 44.1KHz
		Resolution	24 bit
		Bitrate	64Kb/s~384Kb/s (each channel)
Multiplexing			1 ASI input multiplexed with local 4 channels TS
Stream output			2 × ASI outputs, BNC interface
Stream output			MPTS over UDP,10/100Base-T Ethernet interface (UDP unicast / multicast)
System function			LCD/keyboard operating, NMS support,
System function			Ethernet software upgrade
General	Dimensions (WxDxH)		480mm×455mm×45mm
	Approx weight		6Kg
	Temperature range		0~45°C(Operation), -20~80°C(Storage)
	Power requirements		AC 110V/220V±10%,50/60Hz
	Power consumption		17.6W
