Home > Electrical & Electronics > Telecommunication & Broadcasting > Radio & TV Broadcasting > COL5811D DVB-S Headend HD IRD for Irdeto Viacess

COL5811D DVB-S Headend HD IRD for Irdeto Viacess

Name: COL5811D DVB-S Headend HD IRD for Irdeto Viacess
Brand: COLABLE
SKU: 121882853

COL5811D DVB-S Headend HD IRD for Irdeto Viacess thumbnail-1

COL5811D DVB-S Headend HD IRD for Irdeto Viacess photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Sichuan, China

Brand Name:

COLABLE

Model Number:

COL5811D

Contact Supplier Request Quote Chat Now

Colable Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Chengdu/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Sichuan, China

Brand Name COLABLE

Model Number COL5811D

Specifications

IRD HD
1.Factory optional for DVB-T2, DVB-S2/S, DVB-C, DVB-T reception
2.DVB and IPTV mode IP output.

COL5811D IRD-HD

COL5811D provide users a high-level operation experience on H.264 HD video processing to meet the requirements from the Digital TV broadcasting market which is transferring from MPEG-2 SD to H.264 HD today.

The integrated decoder complies with MPEG-4 (AVC high profile level 4.1) and MPEG-2 (MP@ ML&MP@HL) standards, and support Dolby® Digital audio decoding or down-mix and passes through over SDI or AES-EBU or HDMICOL5811Dsupport various optional of reception for DVB-T2*1, DVB-S2/S, DVB-C, DVB-T, TS-over-IP, and ASI Input. Equipped with two CI slots, multi-descramble could be achieved by working with professional CAM modules. The descrambled stream could be delivered to the ASI output port directly, or to the built-in re-multiplexer, or to the IP Output port. Meantime, the decoded video and audio could be outputted via HDMI with one Dolby® Digital audio pass-through or down-mixed PCM, or via HD-SDI with two Dolby® Digital audio and down-mixed embedded, or via YPbPr component interface, or via CVBS plus stereo audio output. The built-in re-multiplexer could accept transport streams rom tuner, two ASI inputs, IP input, and the descrambled stream from CI slot, and output stream could be highly customized thanks to the user-configurable regeneration of PSI/SI tables. Moreover, fully PCR re-mapping, re-use the original NIT or re-generate a new NIT, TS parameters modifications such as TSID, Network ID, and ONID are fully supported on COL5811D. User could take full control and surveillance via Webpage or HDMS (SNMP based network management software) or via the programmer unit locally.

Features

*Factory optional for DVB-T2, DVB-S2/S, DVB-C, DVB-T reception

*MPE(MP@ ML& MP@HLand MPEG 4 Part 10 (AVC high profile level 4.1)
standards compliant and decoding

l Wide choice of I/O interfaces, including ASI input/output, CVBS output, YPbPr output, HDMI output, SD/HD-SDI output (embedded 2 pairs stereos audio), AES/EBU output, 10/100M or 100/1000M TS over IP input/output (optional),

*DS3 interface (optional)

*DS3 in/out interface is compatible with Barco, Huawei protocols

*Built-in re-multiplexer

*BISS 1 or BISS E decryption

*Dynamic PMT detection and automatic update

*VBI TELETEXT, EBU/ DVB SUBTITLE support

*WSS support

*Closed caption support

*10/100M Ethernet TSoIP I/O, compatible for future Gigabit Ethernet daughter board

*UDP and RTP for TS over IP I/O

*DVB and IPTV mode IP output

*Unicast and Multicast support
