Specifications
automatic tin shear machine1 Easy to operate, durable
2 Precision performance
31 year service
1 Main technical parameter
Speed of feeder machine |
0-32pcs/min |
Cutting speed |
0-59m/min |
Application range of iron sheet |
600-1150mm or 600-1250mm |
Thickness of cut iron sheet |
0.15-0.5mm |
Min width of cut iron sheet |
1-6piece |
Min width of horizontally cut iron sheet |
48mm |
Total unit power |
5.45kw |
Dimension |
6650X3880X1530mm |
Weight |
6700kg |
2 The machine is special used to cut thin sheet.
The main Spindle processing forming with a high precision special machine tool, dynamic stability and high precision of feeding material. hob with high strength alloy material is durable
3 The detail picture of machine
4 Sample show
chemical/paint drum/barrels/cans, oil barrels/cans, grease oil cans, food cans, adhesive cans, garbage basket, gasoline cans, spray cans,coffee, tea, biscuit can etc.
5 Customers visit
We have customers all over the world
Our machines are exported all over the world, the main market is in Asia, South and North America, and Africa
6 About our company
Suzhou First Packing Machinery Co,.Ltd
Suzhou First Packing Machinery Co.Ltd was founded in 1997. we specialize in various of tin cans making machines/production line, such as round/square can semi-automatic production line; Conical closed/open barrel can production line, we also provide various two-piece and three-piece can production line
7 Welcome to our company for business negotiation
There always can find the machine that you want
