Help CenterCBB25 25mm Axial Non Polarized Aluminum Electrolytic Capacitor and MEA Metallized Polypropylene Film Capacitor for Audio Speaker
Related Products
-
CBB16-1 16mm Axial Non Polarized Aluminum Electrolytic Capacitor MEA Metallized Polypropylene Film Capacitor for Audio SpeakerUS$ 0.2 - 1.5MOQ: 1000 Pieces -
Axial Non Polarized Aluminum Electrolytic Capacitor and MEA Metallized Polypropylene Film Capacitor for Audio Speaker CBB20 105JUS$ 0.03 - 0.85MOQ: 1000 Pieces
-
CBB16 16mm Axial Non Polarized Aluminum Electrolytic Capacitor and MEA Metallized Polypropylene Film Capacitor for Audio SpeakerUS$ 0.2 - 1.55MOQ: 1000 Pieces
-
UK-300T Hot Sale Guitar Pickup With TunerUS$ 0.01 - 7MOQ: 100 Pieces
-
PS900 Hot Sale Five Band Guitar PickupUS$ 0.01 - 6.9MOQ: 100 Pieces
Howang MPT CBB20 Metallized Polypropylene Film capacitors
•Tech Spec
0.001~82μF ,
100VDC~630VDC,1000VDC AC
-40~105℃
•Features
1.Wide capacitance range
2. Excellent damp proof
3.Excellent stability
• Application
1.Widely used in high frequency power supply
2.Suitable for sound equipment
--------------------------------------------------------------------------------------
Hongwang MPA CBB20A Metallized Polypropylene Film capacitors
•Tech Spec
0.001~82μF ,
100VDC~630VDC,1000VDC AC
-40~105℃
•Features
1.Wide capacitance range
2. Excellent damp proof
3.Excellent stability
• Application
1.Widely used in high frequency power supply
2.Suitable for sound equipment
Special Features
* Small size
* Light weight,
* Excellent self-healing property
* According to RoHS 2011/65/EC
Construction
* Dielectric: Polyester (PET) film
* Capacitor electrodes: Vacuum-deposited
* Encapsulation: Face ends sealed with epoxy resin
Electrical Data
* Capacitance range: 0.001µF to 82µF
* Rated voltages: 50/63Vdc, 100Vdc, 250Vdc,
400Vdc, 630Vdc, 1000Vdc
* Capacitance tolerances: ±10%, ±5%
* Operating temperature range: -40°C to +105°C
* Climatic test category: 55/105/21 in accordance
with IEC
* Voltage derating: A voltage derating factor of
1.25% per K must be applied from +85°C
for DC voltages and from +75°C for AC voltages
ELECTRICAL CHARACTERISTICS
Working Voltage:………………………………….. 6.3 ~ 100V
Operating Temperature:…………………………..-40°C ~ + 105°C
Rate Capacitance Range:…………………… 0.47 ~ 10,000mF
Capacitance Tolerance:………………………….. -20 ~ +20% at the 120Hz
DC Leakage Current(mA):………………………..0.03V or 4mA(after 3 minutes application of rated voltage)
Dissipation Factor: at 120Hz, 25°C
WV(V) |
6.3 |
10 |
16 |
25 |
35 |
50 |
63 |
100 |
DF(%) |
28 |
24 |
20 |
16 |
14 |
12 |
10 |
10 |
For capacitor whose capacitance exceeds 1000mF, the value of DF(%) is increased by 2% for every additional 1000mF.
Load Life: 1000 hours at rated voltage.
Capacitance Change: Within 25% of initial value.
Dissipation Factor: Not exceed 200% of initial requirement.
Leakage Current: Not exceed the initial requirement.
Shelf Life: 500 hours, at rated voltage.
Capacitance Change: Within 25% of initial value.
Dissipation Factor: Not exceed 200% of initial requirement.
Leakage Current: Not exceed 200% of initial requirement.
shippment & payment:
we have our own manufacture factory and the experrienced manufacture team in Huizhou.
we will give you the lower price and the first-class quality.
This quotation doesn't include the shipping charge.
1. All the price are Ex-factory price without retail package.
2. Payment: T/T , Bank Transfer, Western Union and Paypal.
3. Delivery time: 4-7 working days after receipt of payment.
4. Valid period of the offer: 30 days
Delivery time: 12 days
Payment terms: 30% deposit before production, 70% balance before shipment.
| Quality Certificates & Environment Guideline HOWANG holdings has passed TS16949,ISO9001,ISO14001,UL,CQC | |
|
|
|
|
|
|
|
shippment & payment:
we have our own manufacture factory and the experrienced manufacture team in Huizhou.
we will give you the lower price and the first-class quality.
This quotation doesn't include the shipping charge.
1. All the price are Ex-factory price without retail package.
2. Payment: T/T , Bank Transfer, Western Union and Paypal.
3. Delivery time: 4-7 working days after receipt of payment.
4. Valid period of the offer: 30 days
Delivery time: 12 days
Payment terms: 30% deposit before production, 70% balance before shipment.
Attn: Kevin
Whatsapp:+86 18820393453
Wechat: +86 18820393453
Mobile: +86 18820393453
Skype:fax9981 ©
Email: kevincosmetic ©
howangdz ©
tel9981 ©
Add: No. 258. Jianshe road west , Shiwan town, Boluo County, Huizhou city ,Guangdong Province, China.
Tel: 0086-752-6610869
Fax: 0086-752-6610819
Guangdong Huizhou Howang Electronics Co., Ltd
-----------------------------------------------------------------------
