HW-164K Plastic shaft Potentiometer the wholesale price rotary Potentiometer
- 1800000 Piece / Pieces per Month
- shenzhen
- T/T L/C D/P D/A Credit Card PayPal
- 8mm Potentiometer: Horizontal, 10K Ohm+/-10%, with Rotary Switch, Shaft Length 15mm, Used for Walkie Talkies, Radios and Other Instruments and Equipment
- 9mm horizontal single gang rotary potentiometer knob adjustable resistance with rotary switch
- 9mm horizontal single gang rotary potentiometer knob adjustable resistance with rotary switch
- 8mm metal shaft horizontal type dual gang Rotary Potentiometer with rotary switch, use for interpone and Small Audio Device, Small Radio
- 8mm metal shaft horizontal type dual gang Rotary Potentiometer use for interpone and Small Audio Device, Small Radio
- 8mm metal shaft horizontal type rotary potentiometer knob integrated push switch , 10KΩ,adjustable resistance VR
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Howang | Model Number: | HW-164K |
Type: | Rotary Potentiometer | Technology: | Carbon Film | Resistance: | 500 ~1M |
Resistance Tolerance: | 10% | Rated Power: | 0.05W | Max. Operating Voltage: | AC 50V/DC 10V |
Operating Temperature: | -10 ~ +70 |
Product Description
Introdution
1.Closed structure improves dust and flux resistance.
2.Available with bushing, tap and detent.
Electrical characteristics | |
Total Resistance | 1KΩ~1MΩ |
Total Resistance Tolerance | 500Ω1MΩ: ±30% |
Resistance Taper | A, B, C |
Max. Operating Voltage | AC 50V |
Rated Power | 0.05W |
Rotational Noise | Less than 100mV |
Insulation Resistance | More than100MΩ at DC 250V |
Withstand voltage | 1 minute at AC 500V |
Residual Resistance | Term.1~2: Less than 20Ω:Term.2~3: Less than 20Ω |
Gang Error (Dual Unit) | -40db~0db±3db |
Mechanical characteristics | |
Total Rotational Angle | 300°±10° |
Rotational Torque | 30gf.cm~130gf.cm |
Click Torque | 60gf.cm~220gf.cm |
Stopper Strength | Without bushing: 3.0kgf.cm Min.: With bushing: 5.0Kgf.cm Min. |
Push-Pull Strength | 8.0Kgf Min |
Durability | |
Rotational Life | Standard life: 15,000 Cycles Min.: Long life: 100,000 Cycles Min. |
