Home > Packaging & Printing > Packing Machinery > Packing Line > Rectangular Packing Machine for Tin Can

Rectangular Packing Machine for Tin Can

Rectangular Packing Machine for Tin Can photo-1
US$ 4,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Apparel, Beverage, Chemical, Commodity, Food, Other, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware
Packaging Type:
Barrel, Cans
Payment & Shipping
Payment Methods:
Port of Shipment:
Shang port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Apparel, Beverage, Chemical, Commodity, Food, Other, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware
Packaging Type Barrel, Cans
Automatic Grade Semi-Automatic
Driven Type Electric
Voltage 380v
Place of Origin Jiangsu, China
Brand Name First
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Product details

                                      1-4L Square Cans semi-automatic Production line

Name and picture

Technical Specificatins

Slitting Machine GTIB-15
Rectangular packing machine for tin can

Max.sheet thickness:    0.5mm
Sheet Width (mm) :    60-1050mm
Attached engine Power:1.1kw
Net Weight:                  1100 mm
Dimension:         1500×1100×1200mm

Round Shape Roller Machine  CY400

Rectangular packing machine for tin can

Thickness :            ≤ 0.4 mm
Diameter Range: Φ80-Φ 300
Max.Width:           ≤400mm
Capacity:             50-80 cans / min
Power of motor:   0.75Kw
Net Weight:         100Kg
Dimension :       870 x 670 x 920mm

  Welding Machine FB2000-A
Rectangular packing machine for tin can

Power:                  3N.380V/50Hz 15KVA
Welding speed:             ≤ 12m/min
Capacity:                    20~50cans/min
Welding Frequency:   100~250Hz
Diameter Range:        φ65~φ 300mm
Height Range:            70~ 400mm
Overlap:                     0.6~1.2mm
Thickness:                  0.2~0.38mm
Copper Wire Diameter: φ1.5~φ1.7mm T2
Cooling Water :         ≥0.4MPa 10L/min
Net Weight:                    1300kg
Dimension                    1350×1300×1700mm

Hydraulic Square Expanding Machine 3F5Y

Rectangular packing machine for tin can

Size:                 1L_4L
Capacity:    20-30 cans/min
Thickness :      0.15-0.3mm
Net Weight:     700KG
Power:             5.5KW
Dimension:     1400x720x1500mm

Flanging Machine 3FB5
Rectangular packing machine for tin can

Size:               1L_4L
Capacity:   20-30 cans/min
Thickness:   0.15-0.3mm
Net Weight:   350KG
Power:          0.75KW
Dimension: 680x1020x800mm

Seaming Machine GT4A28

Rectangular packing machine for tin can

Capacity :                            8-20cans/min
Lrregular Can(Ddiagonal) : 50 -330mm
Thickness:                             ≤ 0.4mm
Height Range:                     60--400mm
Net Weight:                          800kg
Power of motor :                   2.2kw
Dimension :                       980x580x1900mm

Single Head Ear welding Machine DN40B
Rectangular packing machine for tin can

 Power:             3N38050HZ 40KVA
Thickness:             0.2—0.5mm
Capacity:           25cans/min
Compressed air:300L/min 0.6Mpa
Electrode joumey:    50mm
Net Weight:             320kg
Dimension:           80*60*140mm

 Our advantage

     1).More than 18 years experience and reputation both at home and abroad;

      2).Quality Assurance, excellent after service and reasonable price;

      3).Reliable and safe to control, easy to operate and maintain;

      4).High speed, high production efficiency, save labor force;

      5).Equipped with human-computer interface and PLC; adopt digital control technology;

 Our service

A. one year warranty for the whole system.

B. Free equipment installation and debugging.

C. Atfer one year,we can help you to maintain the machine and accessories are provide only the coat price.

 D. We can help you to design the production line ,workshop and provide turn key project.

 Packing&shipping

Packaging Details: To be packed in plywood case for can machine.

Delivery Detail: 30 days after recived the deposit for  can machine.



Customer visit Rectangular packing machine for tin canRectangular packing machine for tin can

Company information

                                                       Suzhou First Packing Machinery Co,.Ltd



 Suzhou First Packing Machinery Co.Ltd was founded in 1997.it's the profession design can maker machine manufacturer ,the productions are wildly apply to metal container packing field,such as food, beverage,petroleum,chemical industry,paint,coating,and so on.

 we are looking forward to your visit for further negotiation and cooperation.Welcome friends from all over the world to visit our company,we will try our best to serve you .

 We speacilized in various can making such as:

 1-5l round tin canister making line.

 1-4l square can making machine.

10-20l cone tank production equipment.

18-20l round can making equipment.

18-20l rectangular tank production line.

Automatic food can production machines.



FAQ


1. Can your machine meet our needs well?
After receiving your inquiry, we will confirm your packing material, packing volume, bag size, packing speed and precision, and any other requirments, and then give you the proposal according to your specific requirments. Every machine is customized to meet your needs well.


2. Are you factory or trading company?
We are the factory, and especially R&D, manufacture and sell various packing euipments. We have engaged in the packing R&D and production over 10 years.


3. What's your payment way?
T/T by our bank account directly, or by alibaba trade assurance service, or by West Union, or in cash


4. How can we make sure about the machine quality after we put the order?
Before delivery, we will send you the pictures and videos for you to check the quality, and also you can arrange for quality checking by yourself or by your contacts in

the third party inspection organization .


5. We are afraid you won't send us the machine after we send you the money?
Please note our above business license and certificate. And if you don't trust us, then we can use alibaba trade assurance service, guarantee your money, and guarantee your machine's on-time delivery and machine quality.


6. Why we should choose your company?
We are professtional in packing machines over 10 years, and we provide better after-sales service. You guarantee no risk for our deal.



    Welcome to visit our company for business negotiation!
