Introdution
1.Carbon element.
2.Molded case.
3.Wide assortment of resistance tapers.
| Electrical characteristics | |
| Total Resistance | 1KΩ ~1MΩ |
| Total Resistance Tolerance | 20% |
| Resistance Taper | A, B, C, D etc |
| Max. Operating Voltage | Taper B: AC100V Other Tapers: AC70V |
| Rated Power | Taper B: 0.07W Other Tapers: 0.03W |
| Rotational Noise | Less than 100mV |
| Residual Resistance | Term.1~2: Less than 20Ω |
| Term.2~3 | Less than 20Ω |
| Mechanical characteristics | |
| Total Rotational Angle | 200 ± 5° |
| Rotational Torque | 5gf.cm~90gf.cm |
| Rotational Stopper Strength | 2.0Kgf.cm Min. |
| Push-Pull Strength | Push: 1.0Kgf Min |
| Durability | |
| Rotational Life | 10,000 Cycles |
===================================================================================================
HOW to Oder?
