Farm Track Tractor

Farm Track Tractor thumbnail-1
Farm Track Tractor photo-1
US$ 5,190 - 5,250 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
2WD
Contact Supplier Request Quote Chat Now
Shandong Runyuan Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 2WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 35hp
Certificate Other, ISO9001:2008
Brand Name RY
Model Number RY350
Place of Origin Shandong, China
After-sales Service Provided Engineers available to service machinery overseas

farm track tractor



farm track tractor



 35 hp small farming tractor machinary RY350 tractor :

Main Features:

1. The use of a simple floor structure and an external divider is easy for maintenance;

2. The safety frame is optional;

3. The single-acting or double-acting clutch is optional;

4. The various gear configurations, such as 8+2, 8+8 are optional, and the velocity distribution is reasonable to meet different operating needs;

5. The synchronized shuttle shift is optional, and the operation is easy, flexible and reliable;

6. The operations of hydraulic steering, the mandrel cylinder front drive axle are easy and flexible.



farm track tractor

Technical parameters
Drive type 4*2
Overall dimension(L * W * H) 3340*1500*2051
Wheelbase (mm) 1776
Track(front/rear) 1100-1300/960-1460
Track(front/rear) regulating method adjustable /step
Min.Ground clearance(mm) 338
Min.operating weight (without cab)(kg) 1480

Counterweight (max)(front/rear) 60/180
Gears(forward/reverse/creeper) 8+2/8+8
Theoretical speed of each gear(forward/reverse) 1.72-26.02/2.25-10.39;1.72-26.02/1.61-24.24;
Engine
Brand RD350
Engine type In-line, four-stroke
Intake mode Natural intake
Cylinder number 3
Bore 75
Stroke 105
Displacement(L) 1.81
Engine rated power kW@rpm 23.13
Rated speed 2400
Type of air cleaner Dry or wet type
Type of cooling system Forced water-cooled
Max. Torque@ revolving speed (rpm) ≥96/1650
Specific fuel consumption rate at rated conditions(g/Kw.h) ≤244
Fuel tank capacity (L) 29
Steering brake system
Steering brake system Hydraulic
Type of steering gear Cycloid orbitrol steering gear
Type of braking system Dry type or disc type
Transmission system
Clutch type Single action
Gearbox type Two-axis mechanical gearbox
Gearbox shift mode Shift sleeve
Type of central transmission Spiral bevel gear type
Final transmission mode(front/rear) External gearing or built-in type
Walking system
Frame type Frameless
Tire Model (front/rear) 6.00-16/11.2-24
Working device
Type of hydraulic suspension system Open-center, semi-separated or separated type
Type of linkage Three point rear linkage
Linkage classes Class I
Lift capacity(610mm point))kN Ordinary Riser≥5.79
Regulating mode Semi-separated lifter: force and position combination control; separated lifter:depth control and floating control
Type of PTO shaft Rear semi-detached/rear detached type
The number of PTO shaft splines 6 splines/8splines
Outer diameter of PTO shaft spline φ35/φ38
PTO shaft speed 540/760





farm track tractor





To 2013, Runyuan will become an Agricultural Machinery base with capacity of 40 thousand tractors, 100



thousand corn harvesters;and sales income up to 16 billion, tax income 1.5 billion.







Runyuan will seize any opportunity to innovate and enlarge marketing investment, trying to be a famous



AgriculturalMachinery Enterprise both domestic and abroad within 3-5 years.
