Specifications
fluidized bed dryerZLG Series Vibration Fluidized Bed Dryer
Main Introduction:
It is suitable for the operations of drying, cooling for powder or granule raw materials. They may be citric acid, monosodium glutamate, borax, ammonium sulphate, compound fertilizer, piece of radish, bean, less, seed, mine reside and sugar, in chemical, pharmaceutical, foodstuff, grain, mine and so on industries. Use vibration motor as vibration source. It is smooth in running and convenient in maintenance. The noise is low and the life is long; The state of fluidization is uniform and no dead gaps and broken phenomenon. Therefore the dried, cool can be got; It is good in adjustment and width in field of application. The thickness of raw material and the speed of raw material to the speed of raw material to be moved inside the machine and the change of vibration breadth can be realized through steeples. It is small to damage the surface of raw material. So it can be used for raw materials that are easy broken. If the granule is not normal, the effect of process can not be effected; Because of adapting the structure of fully seal, it is effective is clean; The efficiency of machinery and hot is high and the effect of energy saving is good. Compared with ordinal drier, 30-60% of energy can be saved.
Technical Parameters
Model |
Area of fluidized-bed M2 |
Temperature of air in(°C) |
Temperature of Air out(°C) |
Capacity of vaporizing(kg/h) |
Vibration motor Power(Kw) |
ZLG0.3*3 |
0.9 |
70-140 |
40-70 |
20-35 |
0.45*2 |
ZLG0.3*4.5 |
1.35 |
70-140 |
40-70 |
35-50 |
0.75*2 |
ZLG0.45*4.5 |
2.025 |
70-140 |
40-70 |
50-70 |
1.1*2 |
ZLG0.6*4.5 |
2.7 |
70-140 |
40-70 |
70-90 |
1.1*2 |
ZLG0.45*6 |
2.7 |
70-140 |
40-70 |
80-100 |
1.1*2 |
ZLG0.6*6 |
3.6 |
70-140 |
40-70 |
100-130 |
1.5*2 |
ZLG0.75*6 |
4.5 |
70-140 |
40-70 |
120-170 |
1.5*2 |
ZLG0.9*6 |
5.4 |
70-140 |
40-70 |
140-170 |
2.2*2 |
ZLG0.6*7.5 |
4.5 |
70-140 |
40-70 |
130-150 |
2.2*2 |
ZLG0.75*7.5 |
5.625 |
70-140 |
40-70 |
150-180 |
3*2 |
ZLG0.9*7.5 |
6.75 |
70-140 |
40-70 |
160-210 |
3*2 |
ZLG1.2*8 |
9.6 |
70-140 |
40-70 |
200-280 |
3.7*2 |
ZLG1.5*9 |
13.5 |
70-140 |
40-70 |
280-390 |
5.5*2 |
ZLG1.5*10 |
15 |
70-140 |
40-70 |
300-420 |
5.5*2 |
