Specifications
tea bag FFS Packing MachineFor Tea Bag
ISO
CE
GMP
CH-10F Tea Bag FFS Packing Machine
1. All 304 stainless steel cover. Even the exposed screw also adopts the stainless steel material which will be more healthy and meet the GMP standard. (Other's company adopts 201 stainless iron. The exposed screw adopts iron material which will easy to rust).
2. Packaging material adopt the food grade of non-woven fabrics, nylon filters. The bag with high water permeability and visual perspective give the person decorous enjoy.
3.The machine adopt the advanced ultrasonic sealing technology make the products more beautiful.
4.Equipped with independent manipulator technology,thoroughly solved the problem which sent the inner bag into outer bag by hand produce secondary pollution.The new technology make the product more conforming to the hygiene standards, more consumer favorite.
5.The process of bag making,filling,cutting,manipulator sent the inner bag,cursor positioning can be done automatically.
6.This packing machine was researched by our company.It is a high-performance automatic tea bag packing machine which equipment with independent manipulator technology.It will produce the products meet customer's decorous enjoy.
Technical Parameter:
Type |
CH-10F |
inner bag width |
40-80mm |
width of inner bag film |
140mm,160mm |
Bag size of outer bag |
L:60-150mm / W:70-105mm |
Filling range |
1.5-10g(Depending on the tea situation) |
Capacity |
45bag/min |
power |
220V 50Hz 1.8KW |
Compressed air pressure |
0.6Mpa |
air consumption |
200L/min |
