Help CenterDXDY2- 40II Automatic Liquid Packaging Machine
Related Products
-
DXDP-40II Automatic Tablet Packaging MachineNegotiableMOQ: 1 Set -
DXDK-800 Automatic Granule FFS Packing MachineNegotiableMOQ: 1 Set
-
Model DXDK-800 Automatic Granule FFS Packing MachineNegotiableMOQ: 1 Set
-
Model DXDK-800 Granule FFS Packing MachineNegotiableMOQ: 1 Set
-
CH-10F Tea Bag FFS Packing MachineNegotiableMOQ: 1 Set
Specifications
DXDY2- 40II Automatic Liquid Packaging MachineDXDP-40II Automatic Tablet Packaging Machine
Applications:
It is suitable for packaging medicine,original form of food products,tablet,chocolate bean and other granules etc
Features:
1. All stainless steel cover meets to GMP standard.
2. Equipped with antipollution and dustproof device.
3. Automatic adjustment of pouch size and filling range.
4. Photocell controller is easy to manipulate.
5. The horizonal sealing uses high temperature resistant bearing which will ensure the continuous operation of the machine without filling the oil regularly.
6. The operation facility is controlled by American intel computer, all function is displayed with digital screen.
7. Minimum sealing temperature variation employs PID temperature, the tolerance is controlled by
± 2%.
8. Sealing part: roller spend process is special designed and the effect of sealing is very well.
9. Equipped with easy open system.
10. have gained the European CE certification
Option
1.Ink printer
2. Hot pressing codes
Technical Data
TYPE |
DXDP-40II |
Bag size |
L55-110 /W30-80mm |
Capacity |
30-80 bags/min |
Filling range |
1-100 |
Power |
220V,50HZ,1.5KW |
Weight |
350 KGS |
Dimension(L*W*H) |
600X 790X1780 mm3 (L*W*H) |
Depending on product property and filling range
Applications:
The machine is suitable for automatically packaging of viscous products with free-flowing such as shampoo ,lotion, edible oil, broth, honey etc. The integrated processes of bag making, measuring filling, sealing cutting, counting and hot pressing codes can be done automatically.
Feature
1.All stainless steel 304 cover meets to GMP standard.
2.It adopts the suck back function,it will make the sealing effect more beautiful without the clip the material phenomenon.It more suitable packing like honey,shampoo,etc.
3.Equipped with antipollution and dustproof device.
4. Automatic adjustment of pouch size and filling range by computer.
5. Photocell controller is easy to manipulate.
6. Automatic self support lubricating system, the machine can work 24 hours and the maximal capacity is 110 bags/min.
7.Minimum sealing temperature variation employs PID temperature, the tolerance is controlled by ± 2%.
8.The operation facility is controlled by American intel computer, all function is displayed with digital screen.
9. By MC certification, the machine has the capacity to product the measuring instruments which are in line width legal requirement such as accuracy and reliability, etc.
10. By EU certification, comply with the directive requirements of European and confirmed that the products has passed the appropriate conformity assessment procedures and qualified statement of manufactures,meet the requirement of safety.
Recognition certification patent certification
Meter manufacturing license(MC Recognition)
3.Optional products
1.Coding machine(print the date)
2.Hot printing code
3.Stirrer
4,Packing material include several kinds of heat seal lamination, such as PET/plated AL/PE, PET/PE, PAPER/PE,NYLON etc.
Parameter:
Model |
DXDY2-40II |
Bag size |
L:55-110mm/W:30-80mm |
Capacity |
30-80bag/min |
