Home > Products > Packaging machine > JT-420 VERTICAL AUTOMATIC BAG PACKING MACHINE
JT-420 VERTICAL AUTOMATIC BAG PACKING MACHINE
- 30 Unit / Units per Month
- FOB SHANGHAI
- T/T Credit Card
-
CE certificated hydraulic press/Clothes/Bedclothes/Cotton/Woolen/Textile Baler machine
-
20 years manufacturer, automatic hay and straw baling machine
-
more than 20 years factroy supply CE certificated used clothes and textile baling machine
-
more than 20 years factory supply Hard plastic/ Fiber/Cotton/Woolen/Clothes/Textile Baler machine press
-
more than 20 years factory supply plastic baler machine
-
more than 20 years factory supply Clothes/Bedclothes/Cotton/Woolen/Textile Baler machine
Product Details
| Application: | Food | Packaging Type: | Cartons | Automatic Grade: | Automatic |
| Driven Type: | Electric | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
bag packing machineJT-420 VERTICAL AUTOMATIC BAG PACKING
Technical characteristics
1. Siemens PLC control with stable reliable biaxial high accuracy output and color touch screen, bag-making, measuring, filling, printing, cutting , finished in one operation.
2. Separate circuit boxes for pneumatic control and power control. Noise is low, and the circuit is more stable.
3. Film-pulling with servo motor double belt: less pulling resistance, bag is formed in good shape with better appearance, belt is resistant to be worn-out.
4. External film releasing mechanism: simpler and easier installation of packing film.
5. Adjustment of bag deviation just needed to be controlled by the touch screen. Operation is very simple .
6. Close down type mechanism , defending powder into inside of machine.
Application
Suitable for many kinds of measuring equipments, and package different kinds of products ; such as puffy food, shrimp roll, peanut, popcorn, cornmeal, seed, sugar and salt etc. which shape is roll, slice and granule.
Technical parameters :
Type | JT-420 |
Bag length | 50-300mm(L) |
Bag width | 50-200mm(W) |
Max width of roll film | 420mm |
Packing speed | 5-65bags/min |
Measuring range | 150-1200m |
Air consumption | 0.65mpa |
Gas consumption | 0.3m3/min |
Power voltage | 220VAC/50Hz |
Power | 2.2KW |
Dimension | 1080(L) X1300(W) X1400(H)mm |
Weight | 600Kg |
Contact Us
- Shanghai Develop Machinery Co., Limited
- Contact nameLarry Yu
- Phone86-21-56080969
- AddressRm. 1311, Bldg. 2, Lane 926
