used for farm machinery DC70G kubota combine harvester
Company profile
Yancheng Foreign Machinery Parts Co., Ltd.
Yancheng Foreign Machinery Parts Co., Ltd. Mainly produces LIER - G series, D series, K
series, C series, such as four series, hundreds of differentiated products of wheel loader,
capable of producing ten thousand sets of production capacity and in the industry took the
lead through the ISO9001:2000 international quality management system certification and
the national construction machinery quality supervision and inspection center for review,
made of special equipment manufacturing license and received including cross-country
soft double car ", a number of utility model patent. always adhere to the "solidarity, forge
ahead, realistic and innovative" spirit of enterprise, strict quality control, strive for each
product into a boutique. and continuously forge ahead, to "create the first brand of small
loader" as the goal. Excellent product performance, good after-sales service, reasonable
product price for the company to win the broad market, Products are exported to Russia,
Brazil, Argentina, Australia, Iran, Singapore, New Zealand, and many other countries.
Main products
We are YANCHENG FOREIGN MACHINERY PARTS CO., LTD.
We specialized in kubota spare parts, kubota machine ( kubota harvester, kubota transplanter,
kubota tractor).
MACHINE MODEL: 488, 588I, 688Q, 788, 888, DC60, DC68G, DC70, DC95, 704K, 854 ,954,
1004, NSPU68C, NSPU88C, SPW48/68C
KUBOTA machine and Spare Parts are popular in Philippines, Tailand, Vietnam and Sri Lankaand other countries. So glad to talk with you about Different Kubota machines and Spare Parts.
| SPECIFICATION OF KUBOTA DC70G | ||||
| MODEL | DC-70G | |||
| Size | Overall length mm | 4800 | ||
| Overall width mm | 2260 | |||
| Overall height mm | 2990 | |||
| Weight kg | 3030 | |||
| Engine | Model | V2403-M-DI-TE2-CSKC | ||
| Type |
vertical 4 cylinder 4 stroke water-cooled direct injection turbo diesel engine engie |
|||
| Total displacement L[cc] | 2.434[2434] | |||
| Rated output/rpm ps[kw]/rpm | 70/2700 | |||
| Fuel | diesel oil | |||
| Fuel tank capacity L | 85 | |||
| Starting method | starter motor | |||
| Battery V.Ah | 12/65 | |||
| Travel unit | Track | Ground length × width mm | 500X1700 | |
| Centre distance mm | 1300 | |||
| Average ground pressure kpa[kgf]/cm2 | 17.5,0.18 | |||
| Minimum ground clearance mm | 325 | |||
| Transmission mode | hytrostatic CVT HST | |||
| Running speed m/s | low speed:0~0.97; cruising speed:0~1.37; hign speed:0~1.85 |
|||
| Steering | Clutch and Brake | |||
| Cutting | Wo cal control | Rotating diameter×widthmm | 900x1903 | |
| Way up and down adjustment | Hytrostatic | |||
|
Harvest width front-end sub-interval of the grass mm |
2075 | |||
| Cutter width mm | 1980 | |||
| Threshing | Threshing System | Spiked Tooth Axial Flow | ||
| Threshing cylinder | Threshing teeth type | bow teeth | ||
| Diameter × width mm | Φ620 × 1650 | |||
| Rotational speed rpm | 560 | |||
| Screening method | shaker winnowing with 3 air separation | |||
| Grain Tank | Capacity kg/l | 1000 | ||
| Electrical System | 12 Volts Battery Starting, Lighting equipment, Alarms |
|||
| 12 Volts Battery Starting, Lighting equipment, Alarms | ||||
| Electrical System CoolantTemperature, Battery Charge, | ||||
| Harvesting Capacity* ha/hr | ||||
Advantages
1.With the help of Synchro-Shuttle system located under the steering for ease of operation, KUBOTA L Special
tractor can be switched between forward and reverse without stopping. These features make gear shifting
easier, smooth operation and powerful agility.
2.KUBOTA L Special tractor has a great balance between weight, ground clearance and horse power which help you to work in any puddle or cross ridges.
3.With 8 forward, 8 reverse speeds and the proper set speed for each gear, KUBOTA L Special tractor s speed can be chosen to suit with various implements.
4.Two selectable PTO gear speeds; 540 and 750 rpm*, allow you to choose the right speed to suit various working conditions, including soil pulverization by rotary and atomized spraying by boom sprayer.
