G series Internal combustion truck CPCD30 3t counterbalanced forklift truck

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 1000 Piece / Pieces per Month
Port CHINA MAIN PORT
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Jiangsu, China
Brand Name	HELI	Model Number	CPCD30
Type	Powered Pallet Truck	Power Souce	Diesel Engine
Rated Loading Capacity	3000kg

Product Description

G series Internal combustion truck CPCD30 3t counterbalanced forklift truck

Main features
Ergonomics design
1.Using power braking system to reduce footplate strength.
2.Control lever right located to effectively reduce drivers arm tiredness.
3.Dual combined switch lever as a car to enable easy operating.
4.Wide mast with good visibility.
5.Wide space for boarding and driving , increasing leg space.
6.Engine automatic monitor control, when the engine oil pressure is too low or water temperature is too high, the engine will be automatically shut off.
Safety performance
1.Enclose cabin is made of assembling steel plate, high strength overhead is designed to ensure the safety.
2.Parking brake with safety protection device, when parking brake is working, the forklift will not move even the direction lever is turned.
3.Safety device in mast hydraulic system prevents material falling down in case of hose broken.
4.High pressure hose is designed far away from the driver.
5.Safety wire harness, using waterproof plug.

Model		CPCD20	CPCD25	CPCD30	CPCD35	CPQ(Y)D20	CPQ(Y)D25	CPQ(Y)D30	CPQ(Y)D35
Power type		Diesel				Gasoline/LPG
Load capacity	kg	2000	2500	3000	3500	2000	2500	3000	3500
Load center	mm	500
Pallet fork maximum height (with block shelf)	mm	4039	4039	4217	4217	4039	4039	4217	4217
Maximum lifting height	mm	3000
Free hoisting height	mm	145
Overall height (upper frame protection)	mm	2140	2140	2170	2170	2140	2140	2170	2170
Full length (with cargo fork)	mm	3430	3650	3770	3840	3430	3650	3770	3840
Full width	mm	1150	1150	1225	1285	1150	1150	1225	1285
The minimum ground clearance (the door)	mm	110	110	135	135	110	110	135	135
The minimum turning radius (outer)	mm	2170	2240	2400	2420	2170	2240	2400	2420
Least square channel width	mm	2200	2280	2380	2400	2200	2280	2380	2400
Pallet fork abc	mm	92010045	107010045	107012545	107012550	92010045	107010045	107012545	107012550
Maximum speed (full/empty)	km/h	17/19		18/19	19/19	17/19		18/19	19/19
Maximum traction(full/empty)	KN	17/8.33	17/8.88	16/9.8	16.5/9.8	16.4/8.3	16.4/8.3	14.5/9.8	16.5/9.8
Maximum gradeability (full/empty)	%	28/20	25/18	23/20	22/20	26/20	24/18	23/20	20/18
Tire type (before/after)		2/2
Engine manufacturers/models		Kubota V2403			Kubota V3600	NISSAN K21			NISSAN K25
Rated power	KW/rpm	35.4/2400		36.5/2600	46.9/2400	31.2/2250			37.6/2400
Rated torque	Nm/rpm	161.3/1600		164/1500	210/1600	143.7/1600			176.5/1600
Total water (oil)	kg	3480	3800	4400	5000	3480	3800	4400	5000

1.Have rich experience in the machinery parts.

2.10 years research and testing ,It have formed mature and stable system.
3.exporrting more than ten years .

4. Able to produce according your specification .

5. Standard packing or according your specification requested

Company

Manufacture (more than 10 years' experienced factory) exporter

Main export markers

• Easter Europe

• Western Europe

• North America

• Mid East Africa

• Central/South/America

• Asia

• Australia

Long-term cooperated

Customer: Italy, Germany, Spain, Australia etc.

Company advantages

• Guarantee/warranty

• Product performance

• Prompt delivery

• Quality approval

• Service

• Small order accepted

TRADE TERMS

Price Term		(FOB Lianyungang)



Delivery Time		15-25 days from the date of signing the contract and receiving advance payment.



Payment Item		T/T for 30% advance payment and 70% balance payment before shipment



Terms of Shipment		FOB

Port of Shipment		Lianyungang Port, China

Date of Shipment		To be discussed later
