Help CenterHigh Quility of HELI CBD15 Electric Pallet Truck
Related Products
-
Manufacture HELI CBD20 Electric Pallet Truck Configuration No.490NegotiableMOQ: 1 Piece -
HELI CBD20/25/28/30 Electric Pallet Truck Configuration No.460NegotiableMOQ: 1 Piece
-
HELI CBD20/25/28/30 Electric Pallet TruckNegotiableMOQ: 1 Piece
-
HELI CBD20 Electric Pallet Truck Configuration No.410NegotiableMOQ: 1 Piece
-
High Quility of HELI CQD15 AC Electric Reach Truck (sit-sown Type)NegotiableMOQ: 1 Piece
High quility of HELI CBD15 electric pallet truck
Company profile
Yancheng Foreign Machinery Parts Co., Ltd.
Yancheng Foreign Machinery Parts Co., Ltd. Mainly produces LIER - G series, D series, K
series, C series, such as four series, hundreds of differentiated products of wheel loader,
capable of producing ten thousand sets of production capacity and in the industry took the
lead through the ISO9001:2000 international quality management system certification and
the national construction machinery quality supervision and inspection center for review,
made of special equipment manufacturing license and received including cross-country
soft double car ", a number of utility model patent. always adhere to the "solidarity, forge
ahead, realistic and innovative" spirit of enterprise, strict quality control, strive for each
product into a boutique. and continuously forge ahead, to "create the first brand of small
loader" as the goal. Excellent product performance, good after-sales service, reasonable
product price for the company to win the broad market, Products are exported to Russia,
Brazil, Argentina, Australia, Iran, Singapore, New Zealand, and many other countries.
Our company's advantages:
*Hot working atmosphere
*Strong team spirit
*Pay attention to training
*Professional knowledge
*The advanced enterprise idea
*To participate the exhibition
*High qulity products
*Best after-sale service
*Rich products categories
*Own factory, reliable partner to prepare ordwithin shortest time.
Product Description
| 1.5-3T AC Electric Pallet Trucks | ||||||
| Model | CBD15 | |||||
| Configuration No. | 610 | 170G | ||||
| Load capacity | kg | 1500 | 1500 | |||
| Load center | mm | 600 | 600 | |||
| Operator type | Pedestrian-controlled type | Pedestrian-controlled type | ||||
| Wheelbase(not lifting) | mm | 1234 | 1301 | |||
| Goods fork minimum height | mm | 85 | 85 | |||
| Maximum lifting | mm | 205 | 205 | |||
| Max.travelling distance | mm | 120 | 120 | |||
| Overall fork width | mm | 540/600/650/685 | 550/600/650/685 | |||
| Inside width between forks | mm | 220/280/330/365 | 230/280/330/365 | |||
| Fork size | mm | 1150(1200)*160*44 | 1150(1200)*160*55 | |||
| Overall length | mm | 1630 | 1707 | |||
| Overall width | mm | 724 | 697 | |||
| Overall height | mm | 1220/685 | 1181/741 | |||
| Min.Turningradius(pedal retracted/unfolded) | mm | 1400 | 1574 | |||
| Min.Aisle width for pallets 800*1200 | mm | 1817 | 1920 | |||
| Travel speed | km/h | 1858 | 1953 | |||
| Lift speed | mm/s | 3.5/4 | 3/3.5 | |||
| Gradeability | % | 56/60 | 56/60 | |||
| Battery voltage/capacity (5 hours to put battery) |
V/Ah | 5/7 | 5/7 | |||
| Battey weight | kg | 24/70 | 24/70 | |||
| The total battery (reservation) | kg | 48 | 48 | |||
| Service weight with battery | kg | 285 | 275 | |||
TRADE TERMS
| Price Term | (FOB Lianyungang) | |||
Delivery Time |
15-25 days from the date of signing the contract and receiving advance payment. | |||
| Payment Item | T/T for 30% advance payment and 70% balance payment before shipment | |||
| Terms of Shipment | FOB | |||
| Port of Shipment | Lianyungang Port, China | |||
| Date of Shipment | To be discussed later | |||
