Home > Products > CONSTRUCTION MACHINE > Internal combustion truck/CPQ(Y)D10 counterbalanced forklift truck
Internal combustion truck/CPQ(Y)D10 counterbalanced forklift truck
- 1000 Piece / Pieces per Month
- CHINA MAIN PORT
- T/T Credit Card
Product Details
Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | HELI |
Model Number: | CPQ(Y)D10 | Rated Loading Capacity: | 1000kg |
Product Description
Internal combustion truck/CPQ(Y)D10 counterbalanced forklift truck
Model | CPCD10 | CPCD15 | CPCD18 | CPQ(Y)D10 | CPQ(Y)D15 | CPQ(Y)D18 | |
Power type | Diesel | Gasoline/LPG | |||||
Load capacity | kg | 1000 | 1500 | 1750 | 1000 | 1500 | 1750 |
Load center | mm | 500 | 500 | 500 | |||
Pallet fork maximum height (with block shelf) | mm | 4039 | 4039 | 4039 | 4039 | 4039 | 4039 |
Maximum lifting height | mm | 3000 | |||||
Free hoisting height | mm | 152 | 155 | 155 | 152 | 155 | 155 |
Overall height (upper frame protection) | mm | 2140 | |||||
Full length (with cargo fork) | mm | 2936 | 3150 | 3193 | 2936 | 3150 | 3193 |
Full width | mm | 1075 | 1075 | 1090 | 1075 | 1075 | 1090 |
The minimum ground clearance (the door) | mm | 110 | |||||
The minimum turning radius (outer) | mm | 1870 | 1950 | 1980 | 1870 | 1950 | 1980 |
Least square channel width | mm | 1945 | 2025 | 2055 | 1945 | 2025 | 2055 |
Pallet fork a*b*c | mm | 770*100*32 | 920*100*35 | 920*100*35 | 770*100*32 | 920*100*35 | 920*100*35 |
Maximum speed (full/empty) | km/h | 17/18 | |||||
Maximum traction(full/empty) | KN | 17.8/6.9 | 14.2/6.9 | ||||
Maximum gradeability (full/empty) | % | 42/25 | 40/19 | 36/18 | 37/22 | 27/18 | 24/17 |
Tire type (before/after) | 2/2 | ||||||
Engine manufacturers/models | Kubota V2403 | NISSANK15 | |||||
Rated power | KW/rpm | 35.4/2400 | 23.6/2400 | ||||
Rated torque | Nm/rpm | 161.3/1600 | 103/1600 | ||||
Total water (oil) | kg | 2300 | 2760 | 2970 | 2300 | 2760 | 2970 |
1.Have rich experience in the machinery parts.
2.10 years research and testing ,It have formed mature and stable system.
3.exporrting more than ten years .
4. Able to produce according your specification .
5. Standard packing or according your specification requested
Company | Manufacture (more than 10 years' experienced factory) exporter |
Main export markers | • Easter Europe • Western Europe • North America • Mid East Africa • Central/South/America • Asia • Australia Long-term cooperated Customer: Italy, Germany, Spain, Australia etc. |
Company advantages | • Guarantee/warranty • Product performance • Prompt delivery • Quality approval • Service • Small order accepted |
TRADE TERMS
Price Term | (FOB Lianyungang) | |||
Delivery Time | 15-25 days from the date of signing the contract and receiving advance payment. | |||
Payment Item | T/T for 30% advance payment and 70% balance payment before shipment | |||
Terms of Shipment | FOB | |||
Port of Shipment | Lianyungang Port, China | |||
Date of Shipment | To be discussed later |
