WSE-315 ac/dc tig welding machine
- Xiamen China
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | ZZwelder | |
| Model Number | WSE-315 | Voltage | 380V | |
| Rated Capacity | 8.9KVA | Rated Duty Cycle | 60% | |
| Dimensions | 580x334x480mm | Weight | 38KG | |
| Usage | weld aluminum material | Certification | ISO9001/CCC |
Product Description
Specifications
ac/dc welding machine can weld many sort of metal. Such as aluminium,stainless steel, soft steel, carbon steel, cooperWSE Series ac/dc tig welding machine
1.Combining AC and DC in one welder, noise-free.
2.Stable current, easy wire feeding, beautiful welding shape.
3.Protective circuit inside, safe and reliable.
4.Can weld many sort of metal. Such as stainless steel, soft steel, carbon steel,
cooper, alnico and aluminium etc.
WSE-315 Technical Data
Input power voltage(frequency) three phase 380∨ ±10% 50/60HZ
Rate input power capacity(K ∨ A) 8.9
No-load voltage(∨) 60
Output current adjustment range(A) 20-315
Rated output voltage(∨) 23
Rated duty cycle(%)25 °C 80
Arc-start mode HF
Pre-welding gas blow time(s) 0-2
Efficiency(%) 85
Power factor(COS φ) 0.93
Current falling time(s) 5
Post-welding gas blow time(s) 2-10
Weight(KG) 38
Measurement(mm) 580x334x480
Insulation class F
Protection class IP23
Decline time 0-5
Suitable welding thickness(mm) 0.5-12
Packing: Standard carton
