china heli forklift truck price with CPD18
Company profile
Yancheng Foreign Machinery Parts Co., Ltd.
Yancheng Foreign Machinery Parts Co., Ltd. Mainly produces LIER - G series, D series, K
series, C series, such as four series, hundreds of differentiated products of wheel loader,
capable of producing ten thousand sets of production capacity and in the industry took the
lead through the ISO9001:2000 international quality management system certification and
the national construction machinery quality supervision and inspection center for review,
made of special equipment manufacturing license and received including cross-country
soft double car ", a number of utility model patent. always adhere to the "solidarity, forge
ahead, realistic and innovative" spirit of enterprise, strict quality control, strive for each
product into a boutique. and continuously forge ahead, to "create the first brand of small
loader" as the goal. Excellent product performance, good after-sales service, reasonable
product price for the company to win the broad market, Products are exported to Russia,
Brazil, Argentina, Australia, Iran, Singapore, New Zealand, and many other countries.
Our company's advantages:
*Hot working atmosphere
*Strong team spirit
*Pay attention to training
*Professional knowledge
*The advanced enterprise idea
*To participate the exhibition
*High qulity products
*Best after-sale service
*Rich products categories
*Own factory, reliable partner to prepare ordwithin shortest time.
Product Description
| Model | CPD15 | CPD18 | |
| Configuration No. | CJ1/CJ2 | CJ1/CJ2 | |
| Load capacity | kg | 1500 | 1750 |
| Load center | mm | 500 | 500 |
| Standard mast lifting height | mm | 3000 | 3000 |
| Free hoisting height | mm | 155 | 155 |
| Overall height (upper frame protection) | mm | 2160 | 2160 |
| Full length (without pallet fork) | mm | 2130 | 2160 |
| Full width (before/after) | mm | 1070 | 1070 |
| Wheelbase | mm | 1370 | 1370 |
| The minimum ground clearance (the door) | mm | 110 | 110 |
| The minimum turning radius (outer) | mm | 1930 | 1960 |
| Least square channel width (1200 * 1200 mm tray, 20 mm gap) |
mm | 3760 | 3790 |
| Pallet fork length * width * thickness | mm | 35*100*920 | 35*100*920 |
| The door frame Angle(before/after) | deg. | 6/12 | 6/12 |
| Tire type(before/after) | Pneumatic tyres | Pneumatic tyres | |
| Maximum speed (full/empty) | km/h | 14/15 | 14/15 |
| Maximum gradeability (full/empty) | % | 17/25 | 15/23 |
| Hoisting speed (full/empty) | mm/s | 270/450 | 280/530 |
| Battery capacity | V/Ah | 48/550 | 48/550 |
| Control mode (driving, pump) | Ac/dc control | Ac/dc control | |
| The total battery (reservation) | kg | 3000 | 3250 |
| *Ac lifting speed (full/empty) | mm/s | 340/490 | 330/490 |
| *Control mode (driving, pump) | Exchange control | Exchange control |
TRADE TERMS
| Price Term | (FOB Lianyungang) | |||
Delivery Time |
15-25 days from the date of signing the contract and receiving advance payment. | |||
| Payment Item | T/T for 30% advance payment and 70% balance payment before shipment | |||
| Terms of Shipment | FOB | |||
| Port of Shipment | Lianyungang Port, China | |||
| Date of Shipment | To be discussed later | |||
| 1.Reliable AC Traction motor and AC Pump motor which are brushless and maintenance free. | |||||||
| 2.Reliable AC Traction controller and AC Pump controller self-protecting and maintenance free. | |||||||
| 3.Intertactive communication multifunctional LED meter with friendly interface, display mass information, password handing and maintenance free. | |||||||
| 4.Standard CAN BUS interface for simple and reliable communication. | |||||||
| 5.Travel speed and lifting speed closed loop control. | |||||||
| 6.Powerful security, self-braking on ramp. | |||||||
| 7.New technology of dynamic signal load sensing in hydraulic system. | |||||||
| 8.Travel speed normal/cutback choice function. | |||||||
| 9.Electromagnetic compatibility reaches international standards. |
