Sprial steel silo making machine / Steel strip forming machine
Steel silo forming machine,steel silo making machine,spiral steel silo machine is for producing spiral/helix steel silos by strong seaming, not by welding or assembling.
This machine adopts special technology for spiral steel silo, helix steel silo by very strong seaming, not welded or assembled. The technology is same to Lippo Germany. Such steel silo can replace concrete silo in most projects, with much shorter production period and less project cost.
This machine can form 2-4mm thick, 495mm wide galvanized steel, stainless steel or special steel materials into spiral /helix steel silos in diameter 4-50m, for storing corn, paddy, grain, cement, water, chemical materials, etc.
MAIN TECHNICAL SPECIFICATION
Size:Forming machine:1500mm × 1200mm × 1500mm
Curving machine:1500mm× 1200mm ×1000mm
Total Weight: about 3000kg
Press wheels:carbon steel,high-frequency quenching HRC48 - 52
Gears:carbon steel , high-frequency quenching HRC48 - 52.
Sprocket wheel: carbon steel , high-frequency quenching HRC48 - 52.
Thickness of the coil: max 3 mm
Suitable diameter: ≥4m
Electric Standard: 380V / 50 HZ / 3 PHASE
Raw material and thickness:
Galvanized steel: 2-4mm
Chromium-nickel steel: 2-3mm, anti-corrosive
Plastic-coated steel: 2-4mm
Carbon steel: 2-4mm
Width of raw material:495mm
Dia meter range of finished silo:2.5-50m
Height of finished silo: usually less than 30m
Feed speed: 3.5-4.5m/min
The steel silo ( pool wall) are widely used as:
1) Material shape (storage): granular material, powder material, liquid material.
2) Industry: grain, feedstuff, Brewing, oil, medicine, food, cement, water treatment,
etc.
3) Varieties in detail (storage): wheat, soybean, maize, sorghum wheat flour,
bulk cement, fly ash, sewage, water, chemical syrup, etc.
4) Ordinary black steel sheets, galvanized steel sheets, nickeling steel sheets,
high strength steel sheets, stainless steel sheets, aluminum alloy sheets, sand
wich panels, plastic coated metal sheets. Among them, the steel sheets, galva
nized steel sheets, aluminum plate sheets, aluminum alloy sheets, chromium
plate sheets, nickeling steel sheets, sandwich panels can be curved in double
layers.
