HYDRAULIC SX 1250-800 ACM Arch Roof Roll Forming Machine
US$ 70,000 - 110,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Liaoning, China
Brand Name:
Sanxing
Model Number:
SX-1250-800-HY
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
120 SABM-600-305 ARCH TYPE SPAN ROOF BUILDING MACHINENegotiableMOQ: 1 Set -
SX K Q Span 600-305 Hydraulic System Forming Machine/roofing Sheet Bending MachineUS$ 35,000 - 55,000MOQ: 1 Set
-
120 SABM-600-305 ARCH TYPE ROOF STEEL BUILDING MACHINENegotiableMOQ: 1 Set
-
SABM SANXING K Q SPAN COLD ROLL FORMING MACHINENegotiableMOQ: 1 Set
-
ACM 240 AUTOMATIC HYDARULIC CURVING ROOF ROLL FORMING MACHINENegotiableMOQ: 1 Set
Place of Origin
Liaoning, China
Brand Name
Sanxing
Model Number
SX-1250-800-HY
After-sales Service Provided
Engineers available to service machinery overseas
Main Technical Specification of SX1250-800 Arch Roof Roll Forming Machine
Two trailer, with 12 wheels, 3 axles.
Size: 12180mm×1360mm×3600mm
Total Weight: about 18000KG
Main Motor Power: 18.5KW forming power is 7.5kw ; bending power is 4.0kw; cutting power is 4.0kw;
conical power is 3.0kw
Working Speed: Straight sheet: 13m/min
Arch sheet: 13m/min
Sewing: 6m/min
Material of rollers: 45# steel, quenched HRC 58-62
Material of roller shafts: 45# steel
Material of cutting blade: Cr12 steel (Taiwan Airline Technique)
PLC Type: Germany Siemens
Step of rollers: 14 steps
Feeding Width: 1250mm
Effective Width: 800mm
The depth of the groove: 295mm
Thickness of the coil: 0.8-1.5mm
Operating factor of the panel: 64%
Proper span: ≤42m
