Help CenterSX K Q Span 600-305 Hydraulic System Forming Machine/roofing Sheet Bending Machine
Related Products
-
120 SABM-600-305 ARCH TYPE ROOF STEEL BUILDING MACHINENegotiableMOQ: 1 Set -
SABM SANXING K Q SPAN COLD ROLL FORMING MACHINENegotiableMOQ: 1 Set
-
ACM 240 AUTOMATIC HYDARULIC CURVING ROOF ROLL FORMING MACHINENegotiableMOQ: 1 Set
-
SABM 240 AUTOMATIC HYDARULIC CURVING ROOF FORMING MACHINENegotiableMOQ: 1 Set
-
120 SABM SANXING K Q SPAN BENGDING MACHINEUS$ 50,000 - 100,000MOQ: 1 Set
MAIN TECHNICAL SPECIFICATION
1. Size: 10300mm×2250mm×2300mm
2. Total weight: About 9000KG
3. Material of bending leaf: Stainless Steel, 12mm
4. Cutting Material: Cr12, 1MoV, Heat treatment
5. Cutting type: Hydraulic / Mechanical controlling cutting
6. Total motor power: 18.5KW
Forming Power: 7.5KWBending Power: 4.0KW
Cutting Power: 4.0KW Conical Power: 3.0KW
7. Material of rollers: 45# steel, quenched HRC 58-62
8. Material of shafts: 45# steel, adjusted
9.Step of rollers: 13
10. Applicable Span: 38m max.
11.Width of the Panel: Feeding width: 600mm
12. Finished width: 305mm
13. The depth of the groove: 203mm
14. Operating factor of the panel: 61%
15. Thickness of the Panel: 0.8-1.5mm
16.Working Speed: Straight Sheet: 15m/min
Arch Sheet: 13m/min
Seaming: 6m/min
17. Electric Standard: 380V / 50 HZ / 3 PHASES or according to your requirement
18. Controlling system:hydraulic
19. Working procedures: feeding-forming-cutting-curving
Send Inquiry to This Supplier
