Home > Products > New Products > Construction material-prefabricated house steel material-Prepainted galvanized steel plate-anti-corrosiveweather ability

Construction material-prefabricated house steel material-Prepainted galvanized steel plate-anti-corrosiveweather ability

FOB Price

USD $600 - $900 / Ton

25 Tons(Min.Order)

Supply Ability 20000 Ton / Tons per Month
Port Qingdao or others
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Standard	AISI, ASTM, BS, DIN, GB, JIS	Grade	Hot dipped galvanized steel or Alu-Zic Steel SGCC SGCD
Thickness	0.14mm-3.00mm	Place of Origin	Shandong, China
Brand Name	Tai'an hengze	Model Number	PPGI/PPGL/GI/GL/ SGCC, SGCD/DX51D+Z/ DX52D+Z/ DX53D+Z
Type	Other, Steel Plate/ sheet/coil/strip	Technique	Hot Rolled
Surface Treatment	Coated	Application	Other, building material, ,warehouse, roof, Commercial use, furni warehouse
Special Use	High-strength Steel Plate	Width	600mm-1500mm
Length	Depend on the coil weight

Product Description

Specifications

Thickness: 0.14mm-3.00mm.
Width: 600mm-1500mm.
Zinc coating: 40g-265g /m2
Color: all RAL colors to your demands.

1. Certification: our company

(1), Strong corrosion resistance (2), Surface quality

(3), Conducive to deep processing (4), Economy and practicality

2. Product description :

1) AVAILABLE DESIGNATION OF (Prepainted galvanized steel coils) printed PPGI coils

Quality	Q/BQB 440-2003	JIS G3312-1994	EN 10326-2004	ASTM A653-02a
			EN 10327-2004	(BASE PLATE)
			(BASE PLATE)
Commercial Steel	TDC51D	CGCC	DX51D+Z/AZ	CS Type A/B/C
Forming Steel	(TSt01,TSt02,TSt03)	CGCD1	DX51D+Z/AZ	FS Type A, Type B
Drawing	TDC52D /TDC53D	-	DX52D+Z/AZ	DDS TYPE A/C
Steel	TDC52D /TDC53D	-	DX53D+Z/AZ	DDS TYPE A/C
Structural	TS280GD(TStE28)	CGC400	S280D+Z/AZ	SS275
Steel	TS350GD(TStE34)	CGC440	S350D+Z/AZ	SS340 Class1

(2)TREATMENT

Type	Steel coil Steel sheets/plates Corrugated steel sheets/plates
Technique	Hot rolled/cold rolled- galvanized (Zinc/galvalume /Al zinc) - PPGI/PPGL
Surface treatment	Mini/regular/big/zero spangle, Chromate treatment /chromate-free treatment /untreated unoiled/oiled,
Tension leveler skin pass	anti-fingerprint/un-anti-fingerprint, Coating, color

(3) OUR SPECIFICATION OF PPGI/GI

Available Size:

Manufacturer	Thickness	Width	Length of plate	ID coil
HENGZE STEEL	0.14-3.00mm	600-1500mm	depend on the coil weight	508/610mm

Coated Mass OF our PPGI/GI

Base plate	Available Coated Mass(g/m^2)
Galvanized Steel	80, 100, 120, 160, 180
Galvalume Steel	50, 70, 150

(4)Available Painting OF (Prepainted galvanized steel coils) printed PPGI coils:

Category of Painting	Item	Code
	Polyester	PE
	High-durability polyester	HDP
	Silicon modified polyesters	SMP
	Polyvinylidene fluoride	PVDF
	Easy-Cleaning	—
Painting Thickness	Top side: 20+5microns;
	Bottom side: 5~7microns.
Color System	Produce according to RAL Color System or as per buyer’s color sample.
Painting structure	Top surface	Bottom surface
	Primer coating	No coating	1/0
	Primer coating	Primer coating	1/1
	Primer coating + Finish coating	No coating	2/0
	Primer coating + Finish coating	Primer coating or single back coating	2/1
	Primer coating + Finish coating	Primer coating + Finish back coating	2/2

Note: Protect film available

(5) APPLICATION OF OUR PPGI/GI

Construction	Outside	Workshop, agricultural warehouse, residential precast unit, corrugated roof, roller shutter door, rainwater drainage pipe, retailer booth
	Inside	Door, doorcase, light steel roof structure, folding screen, elevator, stairway, vent gutter
Electrical appliance	Refrigerator, washer, switch cabinet, instrument cabinet, air conditioning, micro-wave oven, bread maker
Furniture	Central heating slice, lampshade, chifforobe, desk, bed, locker, bookshelf
Carrying trade	Exterior decoration of auto and train, clapboard, container, isolation lairage, isolation board
Others	Writing panel, garbage can, billboard, timekeeper, typewriter, instrument panel, weight sensor, photographic equipment

3. Product show :

4. Product line:

5. Package: exporting seaworthy packing for PPGI/GI

(1) 4 eye bands and 4 circumferential bands in steel;

(2) Galvanized metal fluted rings on inner and outer edges;

(3) Galvanized metal & waterproof paper wall protection disk;

(4) Galvanized metal & waterproof paper around circumference and bore protection.

6. Load and transport :

7. Color:

8. Application:

Exterior decoration of buildings: Roof and wallboards of industrial, commercial, residential and public facilities

Interior decoration of buildings: Wallboards, ceiling boards, partition boards, fireproof doors, construction material,furniture

Building accessories: Window panels, signboards

Carrying trade:Container Plate, ship plate, warehouse, Commercial use

9. The superiority of product :

(1).Increased supporting strength (2).Reduced project cost (3).Light weight

(4).Easy and fast for installation (5).Durable: 12-20 years (6).Multifold color choices

(7). Non-pollution technology, Moisture resistance, Corrosion resistance, Weather fastness,Beautiful designed

10. Payment terms: 30%TT in advance+70% TT or irrevocable70%L/C at sight or others
