rubber plastic machine industrial mica band heater

Name: rubber plastic machine industrial mica band heater
Brand: Detai
Availability: InStock

FOB Price

USD $10 - $25 / Piece

5 Pieces(Min.Order)

Supply Ability 200000 Piece / Pieces per Month
Port ShenZhen/HongKong
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other, Band Heater, rubber plastic machine industrial mica band heater
Power Source	Electric	Place of Origin	Guangdong, China
Brand Name	Detai	Model Number	DT-7562
Dimension(LWH)	Can be customized	Weight	According the size
Voltage	110-480v	Power(W)	as your requirement
Certification	CQC;CSA;ISO;CE;UL	Warranty	1 year

Product Description

Specifications

rubber plastic machine industrial mica band heater,
1.Widely used in Injection Moulding
2.Film extruderse
3.long service time

rubber plastic machine industrial mica band heater

Jacketed Band Heater

Band Heater is a mainstay product for plastic molding, injection & extrusion machines. They are also ideally suited to heat cylindrical surfaces.

The Band Heater family includes:

Mica Band Heater
Ceramic Band Heater

Nozzle Band Heater

These heaters are available with various Energy saving options in various sheathing materials, viz. Chrome Nickel Steel, Brass, MS, depending upon applications which provides the best combination of physical strength, high emissivity & good thermal conductivity to heat cylindrical parts, good for sheath temperature up to 250⁰C.

Specification

Applicable to the heating components in plastic forming, plastic granulating machines, casting machines, and so on. We are experienced in heater making, and we perform scientific selection of materials and product manufacturing process design under the specific operation conditions of equipment, which help improve the operation security and service life of heating components.

Technique parameter:

1). Specification and size of heater: to be customized as required

2). Heater material: copper, SUS430, SUS304, cast aluminum, cast copper, ceramic

3). Input power: to be customized as required

Characteristics:

1). Applying imported ray materials to ensure operation conditions of components under higher temperatures;

2). Using special manufacturing processes to enhance the heat radiation effect for components;

3). Good electric performance to meet the safety requirements of equipment;

4). Taking the lead in manufacturing processes in the electric heating industry to ensure the longer service life of electric heating parts and components

Technical Datas:

Sheath Material	Chrome Nickel Steel
Insulators	High Grade Steatite Ceramic Insulators (High temperature)
Heat Saving Thermal Insulation	Ceramic Fibre (std.)
Heating Elements (coil)	NiCr 60:16, NiCr 80:20
Nominal Wall Thickness	Premium Heat : ½" Power Saver : ½" + 5/8" (Outer Insulation) Power Saver PLUS :½" + 1.5" ( Outer Insulation)
Connection	Fiber Glass Insulated- Metal Braided Flexible Cable (std. 12" long) mounted on rigid screw post terminals
Voltage Range	110V - 440V, Single
Surface Loading	35-55W / inch² (depending upon model & application)
Power Rating	Depending upon application
Power Tolerance	± 10%
HV Testing	1.5 Kv between heating element and sheath
Insulation Resistance (Cold)	< 20 MΩ
Sheath Temperature	Up to 500°C maximum (Chrome Nickel Steel sheath)
Gap Between the Clamping Edge	5 - 10mm
Resistance	+/- 10%
Width :	Minimum 30mm and there after multiples of 15mm. Minimum 100mm in case of Power saver & Power Saver PLUS
Inner Diameter	Minimum 50mm Minimum 75mm incase of Power saver & 100mm for Power Saver PLUS

Dear customer, this is Kaitlin , the customer service of Detai Electronical Co.,LTD, if you are interested in this product, you can only copy the words of "Hi Kaitlin, I am very interested in this band heater, may I have your price list of it ? " in your inquiry, I will reply you within 8 hours, thank you for your attention .
