Specifications
30A solar controller for home and streetlight useLCD display
parameters can be flexibly set
intelligent
CE,ROHS
30A solar charge controller for home and streetlight use
Instrction:
Product’ functions
CM series controller is a kind of intelligently, multi-purpose solar charge and discharge controller. The family use the fixed LCD display, with a very friendly interface various control parameters can be flexibly set, fully meet your various application requirements. CM series controller has following features.
Features
image of LCD graphic symbol Simple button operation
Automatic Identification System Voltage level Intelligent PWM charge mode
Automatic Temperature Compensation Adjustable charge-discharge control parameters
Settable Operating mode of Load hours Accumulated function of charge and discharge Ampere
Remote monitoring and control function (custom) Battery reverse-discharge protection
Battery reverse-discharge protection Battery reverse connection protection
Overload, Short Circuit Protection
LCD display instruction:
About the Communicate monitoring function
Monitoring interface
Technical Data
Data Model |
CM3024Z |
CM3048 |
Data Model |
CM3024Z |
CM3048 |
Rated Current |
30A |
30A |
Installation cable area. |
≤7# AWG (16mm2) |
|
Rated Voltage |
12V/24V |
48V |
Operating Temperature |
-10°C~60°C |
|
Open Circuit Voltage of solar panel |
No more than 50V |
No more than 100V |
Storage temperature |
-30°C~70°C |
|
Low Voltage Disconnection(LVD) |
10.7V/21.4V |
42.8V |
Humidity requirements |
No more than 90%,no condensation |
|
Float Voltage |
13.8V/27.6V |
55.2V |
Size |
90 mm×188 mm×48 mm |
|
Low Voltage Reconnection(LVR) |
12.5V/25.0V |
50.0V |
Mounting hole spacing |
60 mm×178 mm --Φ5 |
|
No load loss |
No more than 30mA |
weight |
360g |
||
Loop Voltage Drop |
No more than 170mV |
Notes |
Model suffix Z represent automatic identify system voltage level, T represent controller with remote monitoring. |
||
Charging Mode |
PWM mode |
||||
Temperature Compensation |
-4mV/Cell/Degree |
||||
Relate product:
We have CM serise controller with CM2024Z, CM3024Z, CM3048,CM5024Z,CM5048,CM6024Z,CM6048.
Contact with us if you have anything need.
