solar water pump,solar water pump system,solar water pump agriculture
The optimal cost-SD Series: 24V DC direct-drive three-phase PWM frequency energy MPPT tracking solar photovoltaic pumps
2014 upgraded version 24V 3SD / 4SD / 5SD DC direct drive pumps:
PV pump parameters:
Input voltage: 24V
MPPT voltage: 18-36V
Photovoltaic pump power range: 50W-1000W
Flow rate: 1.5 to 10 ton / hr
Head: 15-105 m
Features:
Ultra-efficient motors: three-phase brushless DC motor, smooth operation, high efficiency and long life.
PWM: achieve power controlled by pulse width modulation, non-resonant soft-switching MOS technology to enhance the efficiency of photovoltaic applications.
Frequency: low noise, low power consumption, can be started at low voltage and low temperature conditions.
MPPT Tracking: maximum power point tracking (Maximum PowerPoint Tracking).
Delay soft start: three seconds after the switch is closed, the pump began to work, with a soft start function.
High and low voltage protection: high-voltage protection, under-voltage protection, rainy days, open and close automatically.
Intelligent control and protection: water pumps intelligent protection, over-current protection smart, intelligent overload protection, abnormal working conditions, the pump is automatically turned off.
Super wear-resistant coating of water: 16dB at work the following basic muted, super wear-resistant coating technology water technology industry leader, bearing five years maintenance-free.
Frequency vector pressure sensor: Built-down position-sensitive sensor that can automatically adjust the motor speed according to pressure the state to achieve frequency energy.
CPU automatic scanning and recovery, intelligent control is off, unattended.
Model Number: 150QJ25/9-9.2
| Flow:(m³/h) | Head (m) | Power:9.2KW |
20 |
90 | Specs: 25/9 |
| 25 | 78 | Rated Rpm: 2850r/min |
| 32 | 67 | Pumping Efficiency: 65% |
| 40 | 50 | Frequency:50HZ |
| Input Volatage: DC 540V |
| Output Voltage: AC 0-420v |
| Water pump power: 9.2KW |
| MPPT Voltage: DC 500-600V |
| Open-circuit Voltage: 750V DC |
| MAX Pressure Head: 113 meters |
| Rated Head:78 meters |
| Max Flow: 40 tons per hour |
| Rated Flow:25 tons per hour |
| Water inlet: 152mm |
| Water outlet: 3 inch |
| 1.water Pump*1pc | |||
| 2.300W solar Panel *60pcs | |||
| 3.9.2KW Pumping Inverter*1pc | |||
| 4.water outlet tube & well rope | |||
| 5.100meters cable and well water level sensor * 1pc | |||
| 6.50 meters cable and water tower water level sensor * 1pc | |||
| 7.Cable for water pump 100M |
With high pressure detection protection, under-voltage protection, blocking protection, over-current protection, water protection, water tower water full automatic shutdown function, realize the unattended, intelligent control.
Efficient motor: smooth operation, high efficiency, long life, industrial pumps.
The pump impeller: unique sediment control design.
Variable frequency vector: low noise, low power consumption, but under the condition of low voltage and low temperature start, small power and irrigation with photovoltaic pump life.
MPP Tracking: Maximum power point Tracking (Maximum PowerPoint Tracking).
Germany INFINEON IGBT inverter module, three-phase direct drive frequency energy MPPT tracking solar photovoltaic pumps, used in the harsh conditions of high water and a big lift flow irrigation.
warranty for the solar pump is 1year.
We are sure to offer the world-wide customers with good After-Sales Service.
Please contact us if you have any question or any problem on our products, we are always here at your service!
All the problems will answered within 48 hours.
1. Q: Are you a factory or trading company?
A: We are a manufacturer and exporter for years.
2. Q: Where is your factory located? How can I visit there?
A: Our factory is located in Guangzhou, China. You are warmly welcomed to visit us.
3. Q: Does your company also provide other solar products except solar charge controller regulator?
A: Yes, we also provide other solar products, like mono solar panel, poly solar panel, off grid solar inverter, solar Led light, battery, portable solar system, solar charger, solar junction box, DC fun and other accesories related to the solar power system.
4. Q: How can I get some samples?
A: Please connect me for samples, and my phone number: +86 13878174593.
5. Q: Can the price be cheaper?
A: Of course, you will be offered a good discount for bulk order.
Buy 30A PMW Solar Controller info:
Payment Terms
T/T, L/C are the payment methods we accept at present.
Shipping
Material in stock can be produced (procedure 5-20days) right away after pre-payment confirmation. COSCO Mearsk MSCship to worldwide for safe shipping, don't worry about package damage or loss. It takes about 15-40 days to worldwide, Please note us your contact details include your phone number for easy contacting from shipping company officer.
For more product information, you can also click here:
| Monocrystalline panel solar | Polycrystalline solar panel | off grid solar inverter |
| solar lighting system for home | portable AC solar kits | Solar charge controller |
| Solar kit Radio/MP3/light | DC table/land fan | Solar home 1000w system |
