CE approved Household appliance remote control switch

Specifications

Household appliance remote control switch
1.CE certified
ntrol 2-5 circuits
3.Radio frequency(RF) control

Technical parameter:
1. Working voltage: 180V-240V/50Hz
2. Transmitting voltage: 12V

3. Transmitting distance: 10m ≤ s ≤20m

4. Working frequency: 315MHz
5. Frequency deviation: ±0.2MHz
6. Maximum load power: maximum load 1200W for each circuit



Features:
1. The remote control emitter has the function of delaying to turn off the light.
2. It can load 5 circuits at most.
3. The distance is over 20 meters.
4. The emitter is mobile-shaped emitter and the receivers shell are made from PC material which is fireproof.



Application:
All illumination control for household, offices, markets, hotels, hospitals, warehouses, etc.



Production introduction

Our remote controller adopts imported CPU chip and digital RF technology, coding with large-scale code chip. Remote control and manual control are compatible.

Product Function
Use RF remote control.
Push button 1 and circuit 1 loads on; push button 1 again and circuit 1 loads off.
Push button 2 and circuit 2 loads on; push button 2 again and circuit 2 loads off.
Push button 3 and circuit 3 loads on; push button 3 again and circuit 3 loads off.
Push button 4 and circuit 4 loads on; push button 4 again and circuit 4 loads off.
Push button 5 and circuit 5 loads on; push button 5 again and circuit 5 loads off.
Push button PSD. Then after 70 seconds, the circuits turn off.
Push button PS. The circuits will turn off for 70 minutes and then they will turn on for 3 minutes. This process will continue until cancel it. Push any buttons to cancel this function. (Only WECAN402 and WECAN403 have PS function.)
Push button ON/OFF, then all circuits turn on/off.
