home solar system Off Grid 1kw Solar System for Home Plug and Play
Off grid solar systems are great for those who live in remote locations where bringing in the electric grid is extremely expensive or inconvenient or those who prefer to not have a monthly bill with the electric bill at all.
Off grid solar systems from Silicon Solar will include several critical components, including:
High-Efficiency Solar Panels
Silicon Solar uses the most advanced and high-efficiency solar panels for our off grid solar systems. Designed and engineered to give you more power and a lower-cost, each solar panel used in our grid tie kits is approved and recommended for use all around the world.
Charge Controller
The charge controller is a critical component of any solar power system with a battery backup. Overcharging is a major killer of batteries and a charge controller will monitor the charge level of your batteries and shut down charging to avoid damage once your batteries are full.
Battery Backup
The battery backup is used in these off grid solar systems to provide power during the night or periods of bad weather when your solar panels can not generate enough power for you to use.
DC-AC Inverter
Solar panels and batteries generate and store power in DC (direct current), however nearly all home appliances and electronics use AC (alternating current) power that comes from the electric grid. A DC-AC inverter will transform the DC power from your solar power system into AC power that is useable right through your home's power outlets. A good, high-efficiency DC-AC inverter can make or break the performance and cost-effectiveness of a off grid solar system.
MODEL: Solar Power System SHS12200
| 1. Plug & Play integrated generator | |
| Display | LED screen |
| Controller | Build-in, 30A/12V, PWM |
| Battery | 200Ah/12V, Lead-acid |
| Inverter | Build-in, 1000W modified sine wave |
| Outlet |
DC outlets12V/1A x 4 AC outlets 220V/1000W x 2 |
| USB port | 5V/1A x 2 |
| Grid charging port | 15V/5A x 1 |
| Rating charging current | 30A |
| Rated working voltage | 12V |
| Low voltage protection | 10.7V |
| Low voltage recovery | 12.6V |
| Float charging voltage | 14V |
| 2. Solar Panel | |
| Power | 400W (200W x 2pcs) |
| Cell type | Monocrystalline silicon |
| Number of cell | 72pcs |
| Vmp | 18V |
| Imp | 11.1A |
| Power tolerance | ±5% |
| Voc | 22.32V |
| Isc | 11.54A |
| Operating temperature | -40°c to +80°c |
| Size | 1580*808*35mm |
| Weight | 13kg |
| 3. Other accessories (Optional) | |
| LED Bulb |
12V/5W x2pcs E27 4m's cable with Switch & Socket |
AC charger |
1PC |
Cable for LED bulbs |
1 by 2 Extension Cable 5 meters x 1 |
Cable for Solar Panel |
10 meters for 4m² space |
The integrated generator functions of Solar power system:
1.Battery charging function
2.Low voltage disconnection function(LVD)
3.High voltage disconnection function(HVD)
4.Electronic overload protection
5.Short circuit protection
6.High temperature protection
7.Indicator got working status
8.DC 5V and DC 12V output
| System Type | AC/DC Off Gird Solar Power System | ||||
| Photo | |
|
|
|
|
| Model | SHS1250 | SHS1265 | SHS12100 | SHS12200 | SHS24200 |
| Solar Panel | 100W | 150W | 200W | 2x200W | 2x300W |
| Battery | 50Ah | 65Ah | 100Ah | 200Ah | 2x200Ah |
| Output Power |
300W Modified wave |
500W Modified wave |
600W Pure sine wave |
1000W Pure sine wave |
1500W Pure sine ware |
| Carton Size | 300*180*470mm | 400*180*470mm | 525*248*640mm | 615*302*640mm | 600*550*420mm |
Applicable Scope |
TV, Fan, Radio, Refrigerator, Air-conditioner | ||||
Frequently Asked Questions to the Solar Power System:
Q: Does this solar power system come with everything I need to get started?
A: Yes,the solar power system comes with the solar panels, charge controller, inverter, batteries. You will only need small tools, including a screwdriver and pliers, to properly install the system. It's portable to move, and you do not need an electrician to install this solar power backup generator.
Q: How long will it take to charge the battery from government AC?
A: It will take approximately 8 hours to fully charge the system from AC electrical.
Q: How long will it take to charge the battery by the included 200 Watt solar panel?
A: When exposed to 100% direct sunlight, it will take approximately 8 hours to fully charge the battery.
Q: What types of ports does the solar system have?
A: The system has 2 AC outlets, 4 DC outlets and 2 USB hubs on the front of the unit
Q: Is the Solar Power System 1000W computerized?
A: Yes it is. The LCD digital readout screen displays input and output power, battery level information and the amount of power available to charge the batteries.
Frequently Asked Questions to us:
Q: Are you a factory or trading company?
A: We are a manufacturer and exporter for years.
Q: Where is our factory located? How can I visit there?
A: Our factory is located in Guangdong Province, Guangzhou, China. You are warmly welcomed to visit us.
Q: Does your company also provide other solar products?
A: Yes. We are not only provide solar power system, but slso provide the solar products related to the solar energy, such as moncrystalline solar panel, polycrystalline solar panel, off grid solar inverter, solar lighting system,solar Led lighting, battery, solar charge controller, solar junction box, DC fun and other solar relative accessories.
Q: How can I get some samples?
A: step1:survey-determine your solar needs and solar hours available at your location.
step2:design- choose a pre-engineered system, or have our pros design a custom one.
step3:deliver-purchase your system, get profeesional installation and start saving money.
