High quality 20 w solar panel
Poly-Crystalline solar panel , Poly 156 cell, 36pcs. panel solar,panel solar 250w,panel solar 300w
Quality and Safety
1. Rigorous quality control meets the highest international standards.
2. High-transmissivity low-iron tempered glass, strong aluminium frame.
3. Using UV-resistant silicon.
4. IS09001/14001/CE/TUV/UL
5.3w-300w mono & poly solar panel supply
Warranties
1. 10 years limited product warranty
2. 15 years at 90% of the minimal rated power output
3. 25 years at 80% of the minimal rated power output
High quality 20 w solar panel
Technical Data of 10W mono solar panel pv panel
Model |
SIP-20 |
Maximum Power at ST(Pmax)W |
20Wp |
Maximum Power Voltage(Vmp)V |
18.0V |
Maximum Power Current(Imp)A |
1.11A |
Open Circuit Voltage(Voc)V |
22.0V |
Short Circuit Current(Isc)A |
1.13A |
Cell Efficiency(%) |
17.0% |
Module Efficiency(%) |
15.37% |
Operating Temperature℃ |
-40℃ to +85℃ |
Maximum system voltage |
1000V(IEC)DC |
Power tolerance |
-0.03 |
Temperature coefficients of Pmax |
-0.45%/℃ |
Temperature coefficients of Voc |
-0.27%/℃ |
Temperature coefficients of Isc |
0.05%/℃ |
Weight(kg) |
1.56 |
Number of cell(pcs) |
2*18 |
Related Project
High quality 20 w solar panel
Package & Shipping
Packaging
u Normally packing: 10pc/20pcs per carton
u Individual packing requirement is acceptable.
Shipping
By Sea |
Delivery from Shenzhen or Guangzhou Seaport |
By Air |
Departure from Guangzhou Airport |
By Express |
Post by DHL, EMS, UPS, TNT. |
1. Q: Are you a factory or trading company?
A: We are a factory.
2. Q: Where is your factory located? How can I visit there?
A: Our factory is located in Guangzhou, China. You are warmly welcomed to visit us.
3. Q: Does your company also provide other solar products except mono solar panel?
A: Yes, we also provide poly solar panel, off grid solar inverter, solar Led light, battery, portable solar system, solar controller, solarcharger, solar junction box, DC fun and other accesories related to the solar power system.
4. Q: How can I get some samples?
A: Please connect me for samples, and my phone number: +86 13697413612.
5. Q: Can the price be cheaper?
A: Of course, you will be offered a good price of solar panel for big amount.
High quality 20 w solar panel
Our Service
Buy panel solar 3w to 300w Information:
Payment Terms
T/T, L/C are the payment methods we accept at present.
Shipping
Material in stock can be produced (procedure 5-20days) right away after pre-payment confirmation. COSCO Mearsk MSCship to worldwide for safe shipping, don't worry about package damage or loss. It takes about 15-40 days to worldwide, Please note us your contact details include your phone number for easy contacting from shipping company officer.
Feedback
1. Customer satisfaction is completely guaranteed. If for any reason you are unsatisfied with your order, please contact us first before you leave the feedback.
2. We will do our best to take care of you and if you have any questions please do not hesitate and feel free to contact us at :
For more product info, you can click here:
Off grid solar inverter Solar Panel Portable solar system Solar Led Light
Any questions from you are welcome and will be replied in 24 hours
