Network Transformer
Negotiable
MOQ: 350 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
CORELOGIC
Model Number:
CL1284Z4
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Beijing, China
Brand Name
CORELOGIC
Model Number
CL1284Z4
Usage
Power
Phase
Other
Coil Structure
Toroidal
Coil Number
Autotransformer
network transformer
Customers should test these samples, and assess the test result to determine whether these samples meet technical requirements.
Schematic
1 2 3 4 5 6 7 8 9 10 1 1 12 13 1 4 15 1 6 17 18 1 9 20
40 39 3 8 37 36 3 5 34 3 3 32 31 3 0 29 2 8 27 26 2 5 24 2 3 22 21
Primary Pins4-59-1014-1519-2024-2529-3934-3539-40
Secondary Pins1-36-811-1216-1823-2128-2633-3138-39
No. Item Spec Instrument used
1 Turns Ratio 1:2CT &1:2CT TX&RX
3302 Automatic Transformer test system
Primary DCR 0.60Ω max TX&RX
2 DCR Secondary
DCR
1.20&0.6Ω max
TX%RX
8010 Digital Multimeter
3 OCL 100KHz/0.1V
1.20mH min
TX&RX
LCR Meter
4 LL 100KHz/0.1V 0.6μH max LCR Meter
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
1998
Factory Size
Below 1,000 square meters
Total Employees
201 - 300 People
