Single Chamber Heat Treatment Gas Quenching Furnace up to 1350.C
- 50 Set / Sets per Month
- Qingdao/Shanghai
- L/C Credit Card
Product Details
Condition: | New | Type: | Resistance Furnace | Usage: | Sintering Furnace |
Place of Origin: | Henan, China | Brand Name: | Sutong furnace | Model Number: | ST-CVDQ |
Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Single Chamber High Pressure Gas Quenching Furnace
1.SiC heater
2.Ultimate vacuum degree: about 2Pa
3.Capacity:50~1500kg
ST- series of single chamber high pressure gas quenching furnace consists of furnace body, vacuum system, water cooling system, gas inflation system, gas cooling system, electric control system and furnace outer material car etc. It is used for high pressure gas quenching of materials like high-speed steel, tool & mould steel, high temperature alloy, martensitic stainless steel, titanium alloy ,etc., and also for annealing magnetic material. It has special compacted inner furnace structure, with high-efficiency heat exchanger; it uses inside 360-degree nozzle all around cooling method and the highest gas quenching pressure can reach up to 1MPa. It is configured with optimization designed gas quenching system and electric control system and there is little deformation of components.
Main speicification
Type | ST-CVDQ -223 | ST-CVDQ -335 | ST-CVDQ -447 | ST-CVDQ -669 | ST-CVDQ -7712 | ST-CVDQ -8812 | ST-CVDQ -9912 | ST-CVDQ -101015 |
Power | 30Kw | 57Kw | 75Kw | 140Kw | 200Kw | 250Kw | 300Kw | 350Kw |
Loading Capacity | 50Kg | 100Kg | 200Kg | 500Kg | 700Kg | 800Kg | 1000Kg | 1500Kg |
Effective heating zone (W*H*L) | 200*200*300mm | 300*300*500mm | 450*400*670mm | 600*600*900mm | 700*700*1200mm | 800*800*1200mm | 900*900*1200mm | 1000*1000*1500mm |
Utmost vacuum degree | 2*0.1Pa 4*0.001Pa | 2*0.1Pa 4*0.001Pa | 2*0.1Pa 4*0.001Pa | 2*0.1Pa 4*0.001Pa | 2*0.1Pa 4*0.001Pa | 2*0.1Pa 4*0.001Pa | 2*0.1Pa 4*0.001Pa | 2*0.1Pa 4*0.001Pa |
Highest temperature | 1350°C | 1350°C | 1350°C | 1350°C | 1350°C | 1400°C | 1400°C | 1400°C |
Gas quenching pressure | 2Bar | 2Bar | 2Bar | 2Bar | 2,4,6Bar | 2,4,6Bar | 2,4, 6,10Bar | 2,4, 6,10Bar |
Furnace temp uniformity | ±5°C | ±5°C | ±5°C | ±5°C | ±5°C | ±5°C | ±5°C | ±5°C |
Pressure increasing rate | 0.65Pa/h | 0.65Pa/h | 0.65Pa/h | 0.65Pa/h | 0.67Pa/h | 0.67Pa/h | 0.68Pa/h | 0.68Pa/h |
Note:
We can design and produce according to the users' specific requirements of technical parameters.
Application:
1.Vacuum Gas Quenching: tool steel, alloy steel, stainless steel, copper alloy etc.
1.Vacuum Brazing: brazing of nickel, copper and silver based material
Spare Parts:
Rapid fuse PCS 1
Pipe Seal SETS 1
Vacuum Grease PCS 1
Insulating Ceramic SETS 1
Heater SETS 1
Vacuum Seal SETS 1
Pirani Gauge PCS 2
Thermocouple PCS 1
