ZMT-15 Vibrating electric coal drill
1.Drilling diameter:dia48mm
2.Rated speed:520r/min
3.Drilling depth:60m
ST-ZMT-15 Distant Laneway Water Exploring Drill of Handheld Vibrating and Water Injection.China patent No :ZL-20060115770.1
ST-ZMT-15 Portable Distant Water Exploring Drill for Mine Laneway is a new type water exploring equipment of coal seam in mine laneway and rock formations.Compared with similar products, it is smaller in volume, lighter in weight, easier to carry and simpler to operate, etc..
The maximum drilling depth is 60 m.The concentricity between the end to end of drilling is good . Error is Less than or equal to 50 mm.
Main Specification of Technology:
Items |
Name of Performance Specification |
Measurement unit |
ZMT-15 type |
Factory parameters | |||
|
The Complete (Whole) Machine |
Rated torque |
N·M |
22.5 |
Rated speed |
r/min |
520 |
|
Drilling diameter |
mm |
Φ48 |
|
Drilling maximum depth |
m |
60 |
|
Outside size of the main frame(L*W*H) |
cm |
190×62×940 |
|
weight |
Kg |
19.5 |
|
|
main vabration motor |
type |
—— |
ZM15 |
Rated power |
KW |
1.5 |
|
Rated current |
A |
9 |
|
Rated voltage |
V |
127 |
|
Rated speed |
r/min |
2820 |
Using Environment and Applications Range :
1.Working environment temperature is not more than 40.C, accord with mine laneway regulation index.
2.The relative humidity is not more than 95% (under environment temperature 25 .C).
3.Altitude is not more than 1000 m.
4.Ssuitable for environment containing inflammable, explosive matter such as methane, coal-dust, etc..
5.Mainly used for exploring water and draining off water in mine laneway
