Specifications
1.Titanium sintered filter element2.Withstand heat, high pressures
3.Rugged,fixed pore structure
4.ISO Test
Sintered titanium powder filter element
porous titanium filter elements are designed for applications involving extreme
operating conditions and aggressive fluids and gas.the rugged,fixed pore
structure is constructed from sintered titaniun power.the result is an element
that can withstand heat, high pressures and repeated cleaning/backwash
chanical strength and corrosion resistance are the results of design
with no longitudinal seams.
Features and Benefits:
high corrosion resistance
all sintered titanium construction
backwashable for re-use and maximum economy
multiple end configurations and gasket/o-rings to fit most all vessels.
Filter specifications:
Media: titanium
End caps: titanium
Gaskets/o-rings options: EPDM,Buna-N,Teflon,encapsulated Viton(O-Rings only)
Micron ratings: 0.5,2,5,10,15,35um
Dimensions/Parameters:
Norminal lengths:
10 inch ,20 inch, 30 inchi
(25.4, 50.8, 76.2 cm)
End configuration:
Double open End
226/Flat Single Open End
222/Flat Single Open End
3/4 inch Male NPT
1 inch Male NPT
Outside diameter
2.75 inch(70mm) or 2.36 inch (60mm)
Max. operating temp:700 F(371 C)
Max. differential pressure
250 psid(17.4 bar) forward
50 psid(3.5 bar) reverse
