Help CenterSintered Stainless Steel Fiber Cartridge Filter
Related Products
-
Hypro Stainless Steel Fiber Sintered Filter Element for Generation and Fire Resistant ApplicationsUS$ 20 - 100MOQ: 5 Pieces -
Manfre Supply Cylinder Metallic Filter ElementUS$ 20 - 150MOQ: 10 Pieces
-
China Professional Manufacturer Supply Micron Rating Stainless Steel Metal Filter ElementUS$ 20 - 150MOQ: 10 Pieces
-
Stainless Steel Pleated Filter CartridgeUS$ 15 - 200MOQ: 5 Pieces
-
Professional Manufacturer Supply Pleated Inox Filter CartridgeUS$ 15 - 200MOQ: 5 Pieces
Specifications
1.sintered stainless steel fiber cartridge filter2.custom service
petitive price
Manfre supply the right filter element for you
---Professional Manufacturer
1.Two type filter cartridges you'd like to know
All Manfre cartridges are manufactured from 316L stainless steel throughout. They are available in both plain cylindrical and pleated configurations, using the very latest in high specification media.
1.The plain cylindrical design provides a simple sleeve of filter medium supported by a central core.
2.The pleated design uses pleated media, again supported by the central support core,this time providing over twice the effective filtration area of the cylindrical cartridge.
2.Unique Construction maybe you have interests
In both designs, the construction methed used is the latest, ultra clean TiG and plasma welding system.This method of construction guarantees cartridge integrity, eliminating the risk of bypass and the presence of extractables derived from any bonding agents. Modular assembly up to 745mm(30") long 316L stainless steel TiG welded for ultra clean assemly
3.Different filtation rating you can choose
1.Nominal rated precision woven mesh,available 5-840um
2.Absolute rated sintered metal fiber, available 3-60um
3.Sintered powder media,available 6-60um
4.Special Features Manfre stainless steel filter have
Manfre cartridges are available with many standard industrial end cap configurations and seal materials.They are available with optional outer guards for reverse flow or backwashing to enhance their superior robust design The method of construction and materials used allow for use from -150°C to 300 °C and up to 25 bar differential pressure in normal flow direction.
5.Technical Data for you reference
| Dimensions | Outside Diameter | 66mm |
| Core Diameter | 27mm | |
|
Typical Surface Area (per 10") |
Cylindrical | 0.05 M2 |
| pleated | 0.13 M2 | |
| Recommended Maximum Differential Pressure | Forward Flow | cylindrical :15 bar |
| pleated: 25 bar | ||
| Reverse Flow | 3 bar with backflush support |
6.Convenience and good quality Manfre provide
1.ALL 316L stainless steel construction for wide chemical resistance Choice of precision woven wire, sintered powder and sintered metal fibre media
2.Wide range of ratings from 3um through to 840um
3.TiG welded construction for all grades
4.Full material traceability
5.Suitable for use from -150°C to 300 °C
6.No adhesives or bonding agents used
7.Industries and Applications suit for you
Food and Beverage: Bottled water, Beers, Wines, Flavours
Pharmaceuticals: Membrane pre-filtration
Fine Chemicals: Polymers, Acids, Bases, Solvents
Cosmetics: Alcohol,Creams, Lotions, Waxes, Oil based solution
Water Treatment: Potable water oils, Resin trap, Pre UV, Membrane protection
Automotive: Blanking wash oils, Top Coats, Hydraulic fluids, Solvent wash
Petrochemicals: Amine stream, Glycol solutions, Water injection
