Specifications
1.stainless steel pleated filter element2.Corrosion resistance
3.High porosity,large filter area
4.ISO Test
Stainless steel sintered felt filter element
Main filter media of pleated filter elements are stainless steel sintered fiber felt and
stainless steelwire mesh.
Stainless steel sintered fiber felt is a kind of multiple deep filter media,sintered with
stainless steel fiber at the high temperature.The filter element enjoy the advantage
of high porosity,large filter area and good dirt holding capacity,and can repeated use
after chemical cleaning,etc.
Stainless steel wire mesh is weaved with stainless steel wire.These filter elements
have such characteristics of good strength,fastness,easy cleaning,high temperature
resistance,low cost,etc.Filter rating range from 3 to 200 microns are available,the sizes
is available at customer's requirement.
Application
Mainly used in filtration of high molecular polymer,drug,hydraulic oil,water treatment,
hot gas,etc.
Technical data
Major data of metallic filber sintered felt
| Absolute rating(u) | Bubble point pressure(pa) | Average air permeability(L/dm2/min) | Thickness(mm) | Weight(g/m2) | Porosity(%) | Dirt holding capacity(mg/cm2) |
| 3 | 12300 | 9 | 0.35 | 975 | 65 | 6.40 |
| 5 | 7600 | 34 | 0.34 | 600 | 78 | 5.47 |
| 7 | 5045 | 57 | 0.27 | 600 | 72 | 6.47 |
| 10 | 3700 | 100 | 0.32 | 600 | 77 | 7.56 |
| 15 | 2470 | 175 | 0.37 | 600 | 80 | 7.92 |
| 20 | 1850 | 255 | 0.49 | 750 | 81 | 12.44 |
| 25 | 1480 | 320 | 0.61 | 1050 | 79 | 19.38 |
| 30 | 1235 | 455 | 0.63 | 1050 | 79 | 23.07 |
| 40 | 925 | 580 | 0.66 | 1200 | 77 | 25.96 |
| 60 | 630 | 1000 | 0.70 | 750 | 87 | 33.97 |
1.Above data refers to Bekaert AL3 series web
2.Bubble point press test in accordance to ISO4003
3.Average air permeability in accordance to ISO 4022,the air pressure 200p
4.Dirt holding capacity in accordance to ISO4572,Final pressure drop is 8 times of initial
pressure drop.
we have our own factory!
we have professional technology team!
Welcom OEM. Many kinds of stainless steel filter
elements could be manufactured according to customer's specification.
