Specifications
1.All-stainless steel construction2.Sintered mesh screen media
3.Pleated for high-capacity
4.Consistent and fixed pore size
Description:
Pall Rigimesh sintered metal mesh filter cartridges are constructed from fine-woven
stainless steel wire mesh which is sintered at each wire contact point in a Pall-patented processto produce an
extremely strong surface-sieving porous material with extremely narrow pore size distribution. Unlike unsintered meshes,Rigimesh media will not shift under stress. Sintering also enables the use of finer wires to produce more pores per unit area for higher flow rates and higher contaminant loading capacity. Rigimesh media is pleated to form double open-ended (DOE) MBS1000 style filter cartridges with applications in bulk active pharmaceutical chemical purification processes such as catalyst solids recovery and decolorizing carbon removal. Single open-ended (SOE) AB sanitary and threaded styles are also available.
Features and Benefits
• All-stainless steel construction
• Sintered mesh screen media
• Pleated for high-capacity
• Consistent and fixed pore size
• Corrosion resistant
• High pressure resistant
• Withstands high reverse-flows
• High-temperature capabilities
• Repeatedly cleanable
• No soluble polymeric extractables
• No unloading or shedding
• Absolute rated for reliable performance
• ISO 9000 Certified Quality System
• Manufactured for use in conformance
with cGMP
• FDA-listed materials per 21 CFR
Materials of Construction
Medium 304 L stainless steel
Core and End Caps 304 stainless steel
Gaskets Buna-N(2)
Also available with type 316 L medium and type 316 hardware or with other alloys
(special order)Other polymers available.
Configuration
Double open-ended (DOE)
Flat gasket seals
Single open-ended sanitary AB and threaded styles available.
Nominal Dimensions
Diameters 64 mm (2.5 in.)
Operating Conditions
Maximum Differential Pressure and Temperature
Forward Flow Direction 8.6 bard (125 psid) to 232 °C (450 °F)
Reverse Flow Direction 0.7 bard (10 psid) to 232 °C (450 °F)
Minimum collapse differential pressure.
Temperature limit with Buna-N gaskets: 121 °C (250 °F).
Other gasket materials to 232 °C (450 °F). For Reinforced for 50 psid
(3.4 bard) Reverse-flow option, temperatures to 316 °C (600 °F), or in other alloys to
677 °C (1250 °F), contact your local Pall distributor.
