Specifications
1.String wound filter element2.High filtration efficiency
3.Fit for high capacity systems
4.ISO Certificate
PP string wound filter element
PP string wound filter element provide reliable removal of chlorine,
chemical contamination and sediment from plating bath solutions. The
depth filter media used in the outer zones of the cartridge provides
efficient particulate removal. The inner zone of the cartridge is a
patented extruded carbon block technology that offers significantly
The CEP Series cartridge is certified sulfur free. The PF grade will
not foam or leach additives into a system
Features and Benefits
• Significantly greater VOC removal than conventional granular
activated carbon cartridges of similar physicaldimensions.
• Greater capacity and efficiency in chlorine removal than granular
activated carbon cartridges of similar physical dimensions.
• No channeling, bypassing, fluidizing, or unloading of carbon fines.
• Extruded carbon technology does not release carbon fines during
system start-up unlike conventional granular carbon technology.
• Highly porous and extremely uniform extruded carbon block technology
delivers consistent filtration over time.
• Standard lengths up to 40'' allows for high capacity systems using
conventional filter housings.
• Single Open End cartridge configurations are available to ensure positive
housing seal.
• Configurations available to fit Big Blue® housings.
• Contains no cellulose or other products that could contribute to plating
porosity or bitterness.
• Effective in either continuous or batch processing systems.
Application
• Metal Finishing Processes
• Chemical Filtration
• Process Water
• Aromatic and Solvents
• Plating Bath Solutions
• Parts and Component Rinse Stations
Specifications
| Media |
(outer zone) Polypropylene or Fibrillated Polypropylene (inner zone) Extruded carbon block |
| Gaskets/O-Rings |
Buna-N, Silicone, Viton® , Polyethylene (gaskets only) |
| Outside Diameter |
(nominal) 2.5'' (6.4 cm) (optional) 4.5'' (11.5 cm) 10'' and 20''lengths |
| Inside Diameter | (nominal) 1'' (2.5 cm) |
| Lengths | (nominal) 4, 5, 9.75, 10, 13, 19.5, 20, 29.5,30, 39, 40'' |
