Atalas Compressor Filter Parts/ Compressor Air Filter

Specifications

Manfre air filters are designed to meet or surpass the most stringent requirements for long life, superior air flow, high particle retention and highly effective seals. The standard element frames are sturdily constructed of carbon steel; stainless steel and galvanized steel are also available. Both faces of the radial fin are supported by woven wire, and the unit cores are perforated steel to retain strength for the life of the filter and minimize seal failure.

Manfre offers many different filter medias that remove contaminates as small as 0.3 microns up to 200 microns and provide exceptional performance over wide temperature ranges. Manfre filter medias include:

• Polyester

• Paper

• 80 / 20

• Fire Retardant

• Screen

• Spun Bond

• Others to meet specific applications

Three Filter Styles to Meet Your Specific Application

1.Sewn End Style has a rugged perforated steel core which is attached to pleated woven wire. The filter media covers the frame and end gaskets.

2.Molded End Style also has a sturdy perforated steel core. The filter media is pleated between two layers of woven wire. The core and pleated media is then sealed at both ends with a vinyl rubber seal.

3.Metal End Cap Style is similar in design to the Molded End Style except the core and pleated media is covered at both ends with a metal end cap.
