CNC Advertising Cutting Machine HD-1325

Name: CNC Advertising Cutting Machine HD-1325
Brand: HONGDA BOKE
SKU: 121551567

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

HONGDA BOKE

Model Number:

HD-1325

Beijing Hongda Boke Scien-Tech Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name HONGDA BOKE

Model Number HD-1325

Certification CE

Condition New

Specifications

CNC Advertising cutting machine HD-1325
1.imported linear square guide rail
2.DSP control
3.High-power driver

CNC Advertising cutting machine HD-1325

standard configuration:

1.Whole cast iron stucture, three axies imported square orbits,

2. imported ballscrew, three axies dust proof, water proof,

3.2.2kw imported bearing water cooling spindle,

4.Taiwan made inverters, fully shielded, uneasy distorted cable,

5.U flash disk DSP control system, wentai software, type3 software,

6.20 cutters(φ3.175, φ4, φ6), 3 collets

Technical parameters:

Model	HD1325
XY working area	1250*2440mm
Z working area	>110mm
Table size	1440x3000mm
Max travel speed	8m/min
Max engraving speed	6m/min
Resolution ratio	0.01mm
Reposition accuracy	0.05mm
Max feeding height	120mm
Work-holding	By clamp
Command	G code.u00.mmg*.plt
Surroundings for software	Windows98/2000/xp
Power(not include the spindle)	1500W
Working voltage	AC220V/50Hz
spindle power rate	2.2KW(domestic water cooling)
spindle rotating speed	0-24000rpm/min
Drive motor	stepper
