XLPE Insulated Medium Voltage xlpe 630mm2 power cable
Type:YJV22 8.7/15KV 3x70mm2 ( XLPE Insulated Medium Voltage xlpe 630mm2 power cable )
Rated Working Temperature:0ºC to 90ºC
Short Circuit Temperature:250ºC(Not more than 5s)
Laying Temperature:≥0ºC
Bending Radius:Multi-core≥15D
Construction:
Circular stranded compacted plain copper conductor, extruded layer of cross-linkable semi-conducting screen, cross-linked polyethylene (XLPE) insulation, cross-linked extruded semi-conducting insulation screen, color tape, copper tape metallic screen, three cores assembled together with non-hygroscopic polypropylene filler, wrapped with binder tape, extruded black polyvinyl chloride (PVC) inner cover, armoured by galvanized steel tape, binder tape, PVC or PE over sheath.
Application
- The cable can be used for power transmission and distribution line.
- The cable can be laid indoors, outdoors, in tunnel or in cable trench or dust and directly in the ground in switching stations, between stations and underground to overhead conversion.
- Permissible continuous loading operating temperature is 90℃
- The ambient temperature under installation shall not lower than 0℃
- Permission short circuit temperature shall be 250℃.
-
The bending radius of cable shall not less than 15 times of the diameter of cable.
Standards
International Standard: IEC 60502-2
China Standard: GB/T 12706.2
Other Standards can also be produced as request
Model |
Name |
Application |
|
Cu |
Al |
||
YJV |
YJLV |
XLPE insulated PVC sheathed power cable |
For laying aerial indoors , in-tunnel or cable trench |
YJY |
YJLY |
XLPE insulated PE sheathed power cable |
|
YJV22 |
YJLV22 |
XLPE insulated steel tape armored PVC sheathed power cable |
For laying indoors , in tunnel or cable trench |
YJV23 |
YJLV23 |
XLPE insulated steel tape armored PE sheathed power cable |
|
YJV32 |
YJLV32 |
XLPE insulated thin steel wire armored PVC sheathed power cable |
For laying high-drop, well or underwater |
YJV33 |
YJLV33 |
XLPE insulated thin steel wire armored PE sheathed power cable |
|
YJV42 |
YJLV42 |
XLPE insulated thick steel wire armored PVC sheathed power cable |
Able to bear external mechanical forces, for laying in silo into sea |
YJV43 |
YJLV43 |
XLPE insulated thick steel wire armored PE sheathed power cable |
|
Hebei Wanfang Wire & Cable Group Co., Ltd. established in 2004. Our main and advantage products include 35KV or lower XLPE insulated power cable, 1 and 3 KV PVC insulated power cable, 10 KV or lower aerial cable, pre-branch cable, control cable, computer cable, ACSR, AAC, building cable.
Wooden drum, wooden-steel drum, Steel drum or as your request.
Delivery port: Tianjin/Qingdao/Shanghai
Delivery time: 15 days or as to the qty
Payment term: T/T,L/C
1. Q: Are you manufacturer or trading company?
A: We are Group company with 40000m² total building size, big production capacity.
2. Q:Can you provide Type Test Reports?
A: Yes we can provide type test reports issued by Chinese laboratories.
3. Q:What is your MOQ?
A: You are advised to confirm it with us directly as it’s based on different cable type.
Usually it’s 500 meters for Medium Voltage Cables.
10000 meters for electrical wire.
4. Q:How can I get your price list?
A: Please leave your contact way such as Email/MSN/Skype/Trademanager to us. We will contact to you and send our quotation sheet to you.
5. Q: Required mainly certificates?
A: Our products are certified by ISO9001/ISO14001/CCC/TUV etc.
